| Item | Blower |
|---|---|
| Airflow @ 0.375 In Sp | 890 CFM |
| Airflow @ 0.500 In Sp | 800 CFM |
| Airflow @ 0.750 In Sp | 475 CFM |
| Airflow @ 1.000 In Sp | Not Applicable |
| Airflow @ 1.250 In Sp | Not Applicable |
| Airflow @ 1.500 In Sp | Not Applicable |
| Airflow @ 10.00 In Sp | Not Applicable |
| Airflow @ 11.00 In Sp | Not Applicable |
| Airflow @ 12.00 In Sp | Not Applicable |
| Airflow @ 13.00 In Sp | Not Applicable |
| Airflow @ 2.000 In Sp | Not Applicable |
| Airflow @ 2.500 In Sp | Not Applicable |
| Airflow @ 3.000 In Sp | Not Applicable |
| Airflow @ 3.500 In Sp | Not Applicable |
| Airflow @ 4.000 In Sp | Not Applicable |
| Airflow @ 4.500 In Sp | Not Applicable |
| Airflow @ 5.000 In Sp | Not Applicable |
| Airflow @ 6.000 In Sp | Not Applicable |
| Airflow @ 7.000 In Sp | Not Applicable |
| Airflow @ 8.000 In Sp | Not Applicable |
| Airflow @ 9.000 In Sp | Not Applicable |
| Amps | 5.3/2.7A |
| Assembled/unassembled | Unassembled |
| Assembly | Unassembled |
| Bearing Type | Ball |
| Blower Rpm | 1000 RPM |
| Cfm @ 0.125-in. Sp | 1100 CFM |
| Cfm @ 0.250-in. Sp | 1000 CFM |
| Cfm @ 0.375-in. Sp | 890 CFM |
| Cfm @ 0.500-in. Sp | 800 CFM |
| Cfm @ 0.750-in. Sp | 475 CFM |
| Dba @ 5 Feet | 46 dBA |
| Depth | 15" |
| Discharge Height | 10 3/4" |
| Discharge Height (in.) | 10.75" |
| Discharge Position | Bottom Horizontal |
| Discharge Width | 6 1/2" |
| Discharge Width (in.) | 6.5" |
| Drive Package With Motor Included? | Yes |
| Drive Type | Belt Drive |
| Features | Easily Altered To Required Discharge Position By Drilling New Motor Mounting Holes, Rotating Blower Housing On Base, And Bolting In Position, High Volume At Low Velocity, Motor Is Resilient-Mounted And Automatic Reset Thermal-Protected |
| Finish | Baked Polyester Epoxy |
| Frequency | 60 Hz |
| Full Load Amps | 5.6/2.8A |
| Height | 17" |
| Housing Color | Gray |
| Housing Depth | 15" |
| Housing Height | 17" |
|---|---|
| Housing Material | Steel |
| Housing Material Finish | Baked Enamel |
| Housing Width | 8 3/4" |
| Includes Drive Package | Yes |
| Includes Motor | Yes |
| Inlet Dia. | 9" |
| Inlet Diameter | 9" |
| Manufacturer Warranty Length | 1 yr. Limited |
| Material | Steel |
| Max. Ambient Temp. | 104°F |
| Max. Inlet Temp. | 180°F |
| Maximum Fan Speed | 1000 RPM |
| Maximum Static Pressure | 0.75 in. wc |
| Motor Duty Class | Continuous |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame | 48 |
| Motor Frame Designation | 48 |
| Motor Horsepower | 1/4 hp |
| Motor Hp | 1/4 hp |
| Motor Insulation Class | Class B |
| Motor Speed | 1725 RPM |
| Motor Type | Capacitor Start |
| Nameplate Voltage | 115/230V AC |
| No. Of Inlets | 1 |
| Number Of Speeds | 1 |
| Oem Replacement | No |
| Outlet Dia. | Not Applicable |
| Outlet Height | 10 3/4" |
| Outlet Shape | Rectangular |
| Outlet Type | Non Flanged |
| Outlet Width | 6 1/2" |
| Overall Depth | 15" |
| Overall Height | 17" |
| Overall Width | 11" |
| Phase | 1 |
| Rotation | CW |
| Shaft Dia. | 5/8" |
| Sound Level | 46 dBA |
| Thermal Overload Protection | Yes |
| Type | With Drive Package |
| Voltage | 115/230V |
| Wheel Dia. | 9" |
| Wheel Material | Steel |
| Wheel Type | Forward Curved |
| Wheel Width | 4 1/2" |
| Width | 11" |
| Height (cm) | 43.18 |
|---|---|
| Length (cm) | 38.1 |
| Width (cm) | 27.94 |
| HS Code | 8414802015 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 20.6572 |
