| Item | General Purpose Motor |
|---|---|
| Ambient Temp. | 104°F |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Cc Number | CC029A |
| Composition | Cast Iron |
| Duty Cycle | Continuous |
| Efficiency | 94.5% |
| Efficiency Group | Premium |
| Frame | 405TS |
| Frame Material | Cast Iron |
| Frequency | 60 Hz |
| Full Load Amps | 162A |
| Full Load Amps @ 50hz | 146/150/158/183/188/197A |
| Green Certification Or Other Recognition | NEMA Premium Rated |
| Hp | 150 hp |
| Hp @ 50hz | 125 hp, 150 hp |
| Insulation Class | Class F |
| Length Less Shaft | 26 7/8" |
| Manufacturers Warranty Length | 3 yrs. |
| Max. Ambient Temp. | 40°C |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Cast Iron |
|---|---|
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Three Phase |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 3555 RPM |
| Nema Design | B |
| No. Of Speeds | 1 |
| Nominal Efficiency | 94.5% |
| Overall Length | 31 1/8" |
| Phase | 3 |
| Rpm Range | Over 3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 2 1/8" |
| Shaft Length | 4 1/4" |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 460V AC |
| Warranty | 3 yrs. |
| Motor Thermal Protection | None |
| Height (cm) | 72.2 |
|---|---|
| Length (cm) | 79.06 |
| Width (cm) | 82.2 |
| HS Code | 8501534080 |
|---|---|
| Country Of Origin | BR |
| Weight (kg) | 473.4 |
| Style | Model | Phase | Service Factor | Frequency | Hp | Full Load Amps | Nameplate Rpm | Frame | Rpm | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 01518OT3H254TC | 3 | 1.15 | 60 Hz | 15 hp | 14.9A | 1775 RPM | 254TC | - | $1,928.30 | |
| A | 02018OT3H256TC | 3 | 1.15 | 60 Hz | 20 hp | 19.8A | 1770 RPM | 256TC | - | $2,259.76 | |
| A | 02518OT3H284TC | 3 | 1.15 | 60 Hz | 25 hp | 23.9A | 1770 RPM | 284TC | - | $3,696.74 | |
| A | 03018OT3H286TC | 3 | 1.15 | 60 Hz | 30 hp | 28.3A | 1770 RPM | 286TC | - | $3,782.31 | |
| B | 20018OT3G445T | 3 | 1.15 | 60 Hz | 200 hp | 229A | 1780 RPM | 445T | - | $18,109.69 | |
| B | 20036OT3G444TS | 3 | 1.15 | 60 Hz | 200 hp | 228A | 3575 RPM | 444TS | - | $21,061.41 | |
| C | 01518OT3H254T | 3 | 1.15 | 60 Hz | 15 hp | 14.9A | 1775 RPM | 254T | - | $1,641.39 |
