INGERSOLL-RAND 2475 Air Compressor Pump, Overhung Crankshaft, Cast Iron

Ingersoll Rand 2475 air compressor pump is designed to compress air & deliver it to an air tank for powering pneumatic tools & equipment. This air compressor pump is used in conjunction with an air compressor unit for various applications including automotive servicing, fleet maintenance, body & machine shops; woodworking, production & manufacturing lines, dry cleaning, farming and general maintenance tasks. It features cast iron construction that offers high durability and ensures over 15000 hours of problem free operation. In contrast to petroleum based lubricants, this pump features synthetic lubricant for increasing the pump's efficiency while minimising the damage against high temperatures. This air cooled compressor pump features overhung crankshaft, individually cast cylinders and a one piece connecting rod for minimising & simplifying the maintenance requirement.

Ingersoll Rand 2475 air compressor pump has high efficiency finger valves that provide high pressure & consistent air delivery throughout the operation. This air compressor pump features a magnetic starter which provides a safe way for starting the motor under load. Its oversized industrial grade bearings minimise the friction, thereby extending the pump's durability. Ingersoll Rand air compressor pump's V shape design features finned cylinders for increasing the pump cooling in closed off environments. It features a finned copper intercooler that increases the pump's efficiency while lowering the operating temperature.

Ingersoll Rand 2475 air compressor pump is suitable for driving reciprocating air compressor. This air compressor system is used to run pneumatic tools and equipment for a variety of applications. Various operations in body & machine shops, automotive servicing, fleet maintenance, woodworking, production & manufacturing lines, dry cleaning, farming and general maintenance operations are supported by this compressor pump. Ingersoll Rand air compressor pump is also suitable for powering automated machinery and cutting equipment.

Ingersoll Rand 2475 air compressor pump works by forcing the air into the container and then pressurising it. The electric motor connected to the air compressor pump via gear belts moves the rotor inside the compressor pump. This rotor drives both large & small pistons inside the chamber. While the large piston pulls the air from outside & pushes it into the small piston, the small piston compresses that air supply by pressurising and forces the pressurised air into the compressor tank for storage. The pressurised air inside the air compressor tank is then supplied to pneumatic tools & equipment using a nozzle.

• V-shape design: The finned cylinders & V-shape design of this air compressor pump ensures that the heat generated from the pump operation is easily & efficiently dispersed into the air through radiation. Ingersoll Rand 2475 air compressor pump also features a finned copper intercooler which further lowers and maintains the operating temperature of the pump, thereby increasing efficiency.
• Durable cast iron design: Ingersoll Rand 2475 air compressor pump features cast iron construction which makes it suitable for continuous duty operations. The rugged construction of this pump makes it suitable for over 15000 hours of trouble free usage.
• Splash lubrication: This air compressor pump comes with simple splash lubrication for eliminating any requirement for additional equipment like an oil pump. This also ensures that the pump is easy to maintain & requires minimum maintenance.
• Overhung crankshaft & individually cast cylinders: Ingersoll Rand 2475 air compressor pump features individually cast cylinders and overhung crankshaft for durability. It also features one piece connecting rod to ensure easy maintenance.
• Stainless steel reed valves: Ingersoll Rand 2475 air compressor pump features stainless steel reed valves to ensure increased volumetric efficiency. This feature improves the efficiency & power output of the pump.
• High efficiency finger valves: This air compressor pump has high efficiency finger valves to provide consistent air delivery throughout the operation.

• Compressor air filters: Ingersoll Rand compressor air filters are designed to filter the intake air that passes through the air compressor. Filtered out air prevents any chances of dust / dirt accumulation inside the compressor tank.
• Air compressor controller: Ingersoll Rand air compressor control system is suitable for controlling Ingersoll Rand 2475 air compressor pump. This programmable control system improves the efficiency of the air compressor system by driving control of the pump.
• Compressor oil: Ingersoll Rand compressor oil is suitable for maintaining peak performance for air compressor units at a range of temperatures. This compressor oil offers high thermal conductivity and compressor efficiency while minimising frequent maintenance & downtime. Ingersoll Rand compressor oil offers up to 8000 hours of trouble free run time.

Ingersoll Rand 2475 air compressor pump is manufactured in compliance with ASME standards.

Ingersoll Rand 2475 air compressor pump is installed onto the compressor tank. This compressor pump is bolted on the flat plate, welded on the compressor tank, the output airline is connected to the compressor cylinder. The compressor pump is connected to the motor using belts.
