INGERSOLL-RAND 7100 Air Compressor Pump 2 Stage

Ingersoll Rand 7100 air compressor is designed to compress air and deliver it to an air-powered tool or air tank. It is ideal for the aerospace, automotive, chemical, construction, electronics, food & beverage, MRO, marine, metal & fabrication, mining, oil & gas, pharmaceutical, power generation and shipbuilding industries.

• Ingersoll Rand 7100 air compressor compresses air in two stages.
• It comes with a piston that joins with the crankshaft through a connecting rod.
• The piston moves forward and backwards when the crankshaft rotates, to convert air into high-pressure air.
• The crankcase is connected to the crankshaft, whereas the valves are connected to a cylindrical head containing a valve cavity.
• Owing to the rotational movement of the crankshaft, the piston of the first cylinder also initiates its reciprocating motion.
• The piston sucks air through the filter and suction valve during this process.
• The piston of the low-pressure cylinder compresses the air to an intermediate-pressure air cooler where compressed air is cooled before transferring it to the other cylinder.
• Finally, the high-pressure air collects through the outlet valve.

• Has a 2-stage pump for continuous supply of compressed air.
• Cast iron construction for durability.
• 10 or 15 HP motor with counter-clockwise rotation at a maximum pumping speed of 800 or 1100 RPM, respectively.
• Equipped with overhung crankshaft and flywheel for superior balance and vibration damping.
• 1 inch NPT outlet to deliver air at pressure of 175 PSI.
• Splash lubricated pump and 2-1/2 qt oil capacity for smooth operation.
• Easily removable cylinders for effortless repair and reduced downtime.

• Ingersoll-Rand Start-Up Kits: Electric motor kits comprising 2 inlet air filters, all-season lubricant and a product data sheet.
• Ingersoll-Rand 38440228 Compressor Oil Coolants: Ideal for high & low-temperature applications. Allow the brand's reciprocating compressors to operate at 100% continuous duty.
