SPEEDAIRE 4B237 Electric Air Compressor 3 Hp

Speedaire 4B237 stationary air compressor is an electric-powered pneumatic device that produces & stores compressed air in a storage tank. This Speedaire air compressor is ideal for pneumatic devices like inflation equipment, tire changers, nailers, pneumatic controls & spray guns in the automotive, food & beverage, medical, petrochemical and pharmaceutical industries.

• Choose a clean, well-ventilated location having enough clearance between the compressor flywheel & walls to install the unit.
• Mount the tank over the concrete floor or isolation pads to reduce vibrations.
• Place the motor & compressor over the tank using suitable accessories. Connect the motor, compressor & tank using belt drive flywheel & piping connection.
• Connect the motor to a grounded electrical connection.
• After the power is switched On & the motor starts up, the connected flywheel starts rotating to start up the compressor.
• The compressor's cylinder crankshafts & pistons start moving up & down to intake air.
• The pressurised gas is sent to the air cylinder / tank for further applications. An appropriate filter should be installed to receive air free from water or oil.
• The unit is controlled using an automatic start & stop pressure switch that stops the compressor once a preset receiver tank pressure is reached. When the receiver tank pressure goes below a preset minimum level, the pressure switch restarts the compressor pump again.

• It includes essential components such as a manual drain valve, oil sight glass, pressure gauge and pressure safety valve, facilitating convenient maintenance and ensuring operational safety.
• This UL-listed Speedaire compressor offers a top mounting for space utilisation and accessibility, allowing for easier maintenance and serviceability while maximising the compressor's compact design.
• It has an intermittent duty cycle to provide a balanced and efficient operation, ensuring optimal performance and energy efficiency.
• It has a 0.25-inch NPT outlet for delivering pressurised air.
• This Speedaire compressor unit is fitted with a pressure gauge & pressure safety valve for monitoring the pressure.
• It features cast iron cylinder material and has powder-coated finish, ensuring durability and corrosion resistance for reliable performance.
• This splash-lubricated horizontal compressor features a 30-gallon tank for reliable compressed air supply, ensuring uninterrupted operations.
• This CSA-approved compressor has a maximum operating pressure of 135 psi.
• It has a simplex pump style for providing straightforward and reliable operation for compressed air generation.
• This NEMA 1 rating compressor has a control-type pressure switch for efficient and hassle-free compressor operation.

• Compressor Oils: Speedaire compressor oils are used by this 3 hp air compressor to maintain peak performance & high thermal conductivity, reducing regular maintenance & downtime.
• Stationary Air Tanks: These air tanks replace the old or damaged tanks of this Speedaire 30 gallon air compressor.

• ASME
• CSA
• California Code 462(L)(2)
• UL Listed
• UL1450
• NEMA 1 enclosure
