| Item | Rotary Vane Pump |
|---|---|
| Built-in | Relief Valve |
| Bypass Included | Yes |
| Drive | 0.118" Double Flat |
| Dry Weight | 2.75 lbs. |
| Filter Rating | 120 µm |
| Flow Rate @ 100 Psi | 100 GPH |
| Flow Rate @ 150 Psi | 98 GPH |
| Flow Rate @ 200 Psi | 96 GPH |
| Flow Rate @ 50 Psi | 102 GPH |
| Frame | 48Y NEMA |
| Grade | Grade 303 |
| Height | 3 2/5" |
| Hp | 21/50 hp |
| Hp @ 100 Psi | 1/4 hp |
| Hp @ 150 Psi | 1/3 hp |
| Hp @ 200 Psi | 1/3 hp |
| Hp @ 250 Psi | 1/2 hp |
| Includes | Relief Valve |
| Inlet Size | 3/8" |
| Inlet Type | FNPT |
| Length | 3 3/5" |
| Max. Flow Rate | 100 GPH |
| Max. Head | 6 ft. |
| Max. Motor Speed | 2400 RPM |
| Max. Operating Pressure | 150 psi |
| Max. Operating Temp. | 160°F |
|---|---|
| Max. Relief Pressure | 250 psi |
| Max. Viscosity | 100 cPS |
| Media Type | No |
| Min. Flow Rate | 94 GPH |
| Min. Operating Temp. | -4°F |
| Min. Rpm | 1000 RPM |
| Mounting Type | Clamp On |
| Noise Level | 60 dBA |
| Nsf Certified | Yes |
| Outlet Size | 3/8" |
| Outlet Type | FNPT |
| Ph Range | 6 pH |
| Rotation | Clockwise |
| Rotor Material | Stainless Steel |
| Screen Mesh Size | 100 mesh |
| Seal Material | Carbon Ceramic |
| Series | 1 Series |
| Shaft Material | Stainless Steel |
| Shaft Outside Dia. | 1/2" |
| Static Pressure | 100 psi |
| Strainer Area | 3.25 sq. in. |
| Strainer Type | Integral 100 Mesh Wire |
| Tds Resolution | 5000 ppm |
| Valve Configuration | Standard Non External Adjust |
| Vane Material | Carbon |
Procon 111A100F11AA rotary vane pump is a versatile and efficient positive displacement pump used in various industries for fluid handling applications.
| Height (cm) | 9.78 |
|---|---|
| Length (cm) | 8.71 |
| Width (cm) | 9.25 |
| HS Code | 8413500090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 1.0935 |
The pump requires a maximum mechanical horsepower of 0.42 hp (313 W).
The maximum flow rate of this Procon 111A100F11AA rotary vane pump is 100 gallons per hour (300 litres per hour).
Procon 111A100F11AA rotary vane pump comes with NPT 3/8 inch inlet and outlet connections.
| Style | Model | Mounting Type | Max. Flow Rate | Max. Operating Pressure | Seal Material | Shaft Material | Flow Rate @ 150 Psi | Flow Rate @ 200 Psi | Flow Rate @ 50 Psi | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 111A035F11CA | Carbonator Clamp | 35 GPH | 150 psi | Carbon, Ceramic | Stainless Steel | 33 GPH | 31 GPH | 37 GPH | $145.25 | |
| A | 111A140F11AA | Carbonator Clamp | 140 GPH | 150 psi | Carbon, Ceramic | Stainless Steel | 139 GPH | 137 GPH | 143 GPH | $145.25 | |
| A | 141A140F11AA | Carbonator Clamp | 140 GPH | 150 psi | Carbon, Ceramic | Brass | 139 GPH | 137 GPH | 143 GPH | $153.81 | |
| A | 141A125F11AA | Carbonator Clamp | 125 GPH | 150 psi | Carbon, Ceramic | Stainless Steel | 124 GPH | 122 GPH | 128 GPH | $153.81 | |
| B | 101b100F11BC | Clamp On | 100 GPH | 60 psi | EPDM, Nitrile | Stainless Steel | 98 GPH | 96 GPH | 102 GPH | $92.20 | |
| B | 101C100F11BC | Clamp On | 100 GPH | 60 psi | Carbon Ceramic | Stainless Steel | 98 GPH | 96 GPH | 102 GPH | $135.70 |
