FUNCTIONAL DEVICES INC / RIB PSH100A100AB10 Class 2 Transformer 24vac 100 Va 1 Ph

Functional Devices PSH100A100AB10 transformer is used in low-current scenarios, especially in building automation (BAS) panels, industrial enclosures and general-purpose electrical enclosures. This RIB transformer is designed for ON / OFF control, equipment overcurrent protection, power indication and high / low voltage separation.

• When an electric current passes through the coil (electromagnet) of the relay, it generates a magnetic field.
• This magnetic field attracts an armature or iron core, causing a set of contacts (switch) to move.
• The movement of these contacts either completes or interrupts the circuit.
• The state of the contacts (open or closed) governs the current flow in the main circuit connected to the relay.
• Relays are commonly employed to regulate a high-current circuit with a low-current signal.
• For instance, a small control voltage can activate the relay, which, in turn, switches a larger load.

• The primary connection is facilitated through pigtails, ensuring ease of installation and maintenance.
• Its secondary connection utilises screw terminals, providing a secure and reliable electrical connection.
• This relay is designed to be efficient and convenient with an enclosed enclosure style, enhancing the safety and protection of the internal components.
