| Item | Table Saw Motor |
|---|---|
| Ambient Temp. Range | 40°C |
| Amps | 22/11A |
| Bearing Type | Ball |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 |
| Cord Length | 54" |
| Design Code | L |
| Drive End Bearing Size | 6205 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Saw |
| Efficiency | 71% |
| Electrical Type | Capacitor Start, Induction Run |
| Enclosure Type | Tefc |
| Extended Thru-bolts | No |
| Frame | 143Y |
| Frame Length | 7 1/2" |
| Frame Material | Rolled Steel |
| Frame Type | 143Y |
| Frequency | 60 Hz |
| Full Load Amps | 22/11A |
| Height | 12 22/25" |
| Hp | 2 hp |
| Hz | 60 Hz |
| Includes | 54" Long Cord |
| Ins. Class | Class B |
| Insulation Class | Class B |
| Ip Code | IP43 |
| Kva Code | J |
| Kw | 1.5 kW |
| Length | 17.94" |
| Length Less Shaft | 11 1/8" |
| Max. Ambient Temp. | 40°C |
| Max. Rpm | 3450 RPM |
| Motor Application | Power Tool |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
|---|---|
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face |
| Motor Orientation | Horizontal |
| Motor Service Factor | 1 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | Counter Clockwise Shaft End |
| Motor Type | Capacitor Start |
| Mounting Type | Face |
| Nameplate Rpm | 3450 RPM |
| No. Of Phase | 1 |
| No. Of Poles | 2 |
| No. Of Shafts | 1 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 70% |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Overall Length | 12 7/8" |
| Phase | Single |
| Power Factor | 78 |
| Rpm | 3400-3600 RPM |
| Service Factor | 1 |
| Shaft Dia. | 3/4" |
| Shaft Length | 1 3/4" |
| Shaft Type | Single Special Extension |
| Standards | Csa Certified, Ul Recocgnized |
| Starting Method | Across The Line |
| Thermal Protection | No Protection |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 115-230V |
| Width | 13.06" |
| Motor Thermal Protection | None |
| Height (cm) | 32.72 |
|---|---|
| Length (cm) | 45.57 |
| Width (cm) | 33.17 |
| HS Code | 8501406040 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 20.25 |
| Style | Model | Voltage | Hp | Frame | Motor Shaft Rotation | Phase | Full Load Amps | Insulation Class | Nominal Efficiency | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 120925.00 | 115-230V | 1 1/2 hp | 143Y | Counter Clockwise Shaft End | Single | 20/10A | Class B | 69% | $1,453.02 | |
| B | 120728.00 | 230V | 3 hp | 145Y | CCWSE | Single | 13A | Class F | 81.5% | $2,104.05 | |
| C | 120998.00 | 230V | 4 hp | 145Y | Counter Clockwise Shaft End | 1 | 17.6A | Class F | 84% | $1,654.38 |
