| Item | Flange |
|---|---|
| Bore Dia. | 3 7/8" |
| Bore Size | 3 mm |
| Bore Tolerance | +0.0005" to +0.002" |
| Bore Type | Finished With Keyway |
| Coupling Size | 11 |
| Flange Length | 1 1/2" |
| Hub | Shaft Hub |
| Hub Dia. | 5 5/8" |
| Hub Flange Type Code | S |
| Hub Length | 1.562" |
| Keyseat Size (in.) | 1" x 1/4" |
| Length Through Bore | 0.188" |
| Material | High Strength Cast Iron |
| Max. Angular Gap Misalignment | 0.151" |
| Max. Angular Misalignment | 1° |
|---|---|
| Max. Parallel Misalignment | 0.032" |
| Max. Speed | 3600 RPM |
| Outside Dia. | 8 5/8" |
| Set Screw Distance | 1 1/4" |
| Set Screw Thread Size | 3/4"-10 |
| Set Screw Thread Type | Coarse |
| Setscrew Length | 1/4" |
| Setscrew Location | One Over Ks And @ 90° |
| Setscrew Torque Requirement | 23 lbs.-in. |
| Sf Hub Length | 1.562" |
| Size | 11 |
| Torque | 1028 N-m |
| Type | Sure-Flex Type S Bts Flange |
| Height (cm) | 14.3 |
|---|---|
| Length (cm) | 21.92 |
| Width (cm) | 2.54 |
|---|---|
| Weight (kg) | 7.29 |
