CHICAGO PNEUMATIC CP7782-6 Air Impact Wrench, 1 Inch Drive, 6 Inch Anvil

Item: AC7ZWN
Model: CP7782-6
Cross Ref: 39D664
Check Availability
In Stock.

Get it by Friday, Feb 6

£9.99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates

We deliver to your doorstep under DAP terms. Customs clearance is for your account

$1,222.57
10% off
$1,100.31 /unit (ex. VAT)
Add To Cart
Request Quote

Unlock 30-day payment terms

Business customers can apply for Net 30
No fees, No interest, Fast approval.

Payment

Delivery

Specifications

Item Air Impact Wrench
Air Consumption 41 CFM
Air Inlet Size 1/2"
Air Inlet Type NPT
Anvil 6" Extended
Anvil Size 6"
Average Cfm @ 15 Second Run Time 10 CFM
Breakaway Torque 1920 lbs.-ft.
Built-in Light No
Cfm @ Full Load 40.7 CFM
Clutch Style Rocking Dog
Drive Size 1" Square
Drive Type Extended
Duty General
Duty Rating General Duty
Exhaust Location Bottom
Extended Anvil Length 6"
Fastening Torque 1475 lbs.-ft.
Features Ergonomic Side Handle, Full Teasing Trigger, Integrated Protective Cover On The Clutch Housing, Low Vibration For A Better Operator Comfort
Free Speed 5200 RPM
Handle Material Aluminum
Handle Type D
Housing Material Aluminum
Impact Rated Yes
Impact Sound Level 111 dB
Impacts Per Minute 500
Maximum Air Pressure 90 psi
Maximum Bolt Capacity 1"
Minimum Air Pressure 90 psi
Minimum Hose Size 1/2"
Number Of Speed Settings 3
Overall Length 20 3/8"
Power Source Air Powered
Power To Weight Ratio 86.5 lbs.-ft.
Required Pressure 90 psi
Retainer Type Friction Ring, Through Hole
Square Drive Size 1"
Style D Shaped
Tool Style Compact
Tool Weight 25.6 lbs.
Torque Range 440 lbs.-ft. to 1850 lbs.-ft.
Vibration Level 7.8 m/sq. sec.
Standards EN ISO 11148-6:2013, ISO 15744, ISO-28927-2

Product Details

    • Designed for loosening lug nuts from vehicles; can also be used for high-torque applications
    • Comes equipped with a 6-inch extended anvil, 1-inch straight impact wrench, an ergonomic side handleand a full teasing trigger which ensures precise operation compact spaces
    • Features a powerful motor with a reinforced clutch mechanism that can produce a maximum torque of 1920 ft-lb in reverse
    • Regulator with 3 position power setting in both forward and reverse directions provides control

Shipping Information

Height (cm) 15.24
Length (cm) 57.15
Width (cm) 22.1
HS Code 8467115040
Country Of Origin TW
Weight (kg) 12.6
