| Item | IEC Frame AC Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 24.9-23.6/11.8A |
| Assembly | B3 |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Class | Stock |
| Code | G |
| Conduit Box Position | B3 |
| Design Code | B |
| Enclosure Design | TEFC |
| Frame | D132S |
| Frame Size | D132S |
| Frequency | 60 Hz |
| Full Load Amps | 24.9-23.6/11.8A |
| Hp | 7 1/2 hp |
| Insulation Class | Class F |
| Ip Rating | IP54 |
| Lead | 9#14 |
|---|---|
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Multiplier | L1 |
| Nameplate Rpm | 3490 RPM |
| No. Of Motor Leads | 9 |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 90.2% |
| Output Kw | 7.5 kW |
| Phase | 3 |
| Proprietary | No |
| Revision | B |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.15 |
| Shaft Rotation | Reversible |
| Type | 3729M |
| Voltage | 208-230/460V |
| Wire Size | 14 AWG |
| Xp Class And Group | None |
| Height (cm) | 41.28 |
|---|---|
| Length (cm) | 67.63 |
| Width (cm) | 42.23 |
| HS Code | 85015220 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 53.55 |
