| Item | IEC Frame AC Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 52-50/25A |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Break-down Torque | 218 lbs.-ft. |
| Class | Stock |
| Code | H |
| Conduit Box Position | F2 |
| Design Code | A |
| Enclosure Design | TEFC |
| Frame | D160L |
| Frame Size | D160L |
| Frequency | 60 Hz |
| Full Load Amps | 52-50/25A |
| Full Load Torque | 59.1 lbs.-ft. |
| Hp | 15 hp |
| Insulation Class | Class F |
| Ip Rating | IP54 |
| Lead | 9#10 |
| Line-line Res. @ 25° C | 0.335 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 118 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | Rigid Base |
|---|---|
| Multiplier | L1 |
| No Load Amps | 11.3A |
| No. Of Motor Leads | 9 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 93% |
| Output Kw | 15 kW |
| Phase | 3 |
| Proprietary | No |
| Pull-up Torque | 76.9 lbs.-ft. |
| Revision | E |
| Rpm | 1700-1800 RPM |
| Service Factor | 1.15 |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 167A |
| Temp. Rise @ Rated Load | 61°C |
| Temp. Rise @ S. F. Load | 73°C |
| Type | 0960M |
| Voltage | 208-230/460V |
| Wire Size | 10 AWG |
| Xp Class And Group | None |
| Height (cm) | 44.29 |
|---|---|
| Length (cm) | 68.58 |
| Width (cm) | 52.07 |
| HS Code | 85015230 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 140.85 |
