| Item | IEC Frame AC Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 19.4-18/9A |
| Base Indicator | Rigid |
| Break-down Torque | 40.4 lbs.-ft. |
| Class | Stock |
| Code | J |
| Conduit Box Position | B3 |
| Design Code | A |
| Efficiency | 89.5% |
| Enclosure Design | TEFC |
| Frame | D132S |
| Frame Material | Steel |
| Frame Size | D132S |
| Frequency | 60 Hz |
| Full Load Amps | 19.4-18/9A |
| Full Load Torque | 10.7 lbs.-ft. |
| Hp | 5 1/2 hp |
| Insulation Class | Class F |
| Ip Rating | IP54 |
| Leads | 9#14 |
| Line-line Res. @ 25° C | 1.1 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 21.8 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | Foot Mounted |
|---|---|
| Multiplier | L1 |
| Nameplate Rpm | 3520 RPM |
| No Load Amps | 3.73A |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 89.5% |
| Output Kw | 5.5 kW |
| Overall Length | 17.66" |
| Phase | 3 |
| Proprietary | No |
| Pull-up Torque | 20.6 lbs.-ft. |
| Revision | A |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 38 mm |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 68.4A |
| Temp. Rise @ Rated Load | 44°C |
| Temp. Rise @ S. F. Load | 54°C |
| Type | 3728M |
| Voltage | 208-230/460V |
| Xp Class And Group | None |
| Height (cm) | 38.42 |
|---|---|
| Length (cm) | 54.93 |
| Width (cm) | 40.96 |
| HS Code | 85015220 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 53.1 |
