| Item | IEC Frame AC Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps @ 208v | 13.9A |
| Bearing-drive-end | 6206 |
| Bearing-opp-drive-end | 6205 |
| Design Code | B |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Efficiency | 89.5% |
| Efficiency @ 100% Load | 89.5% |
| Enclosure Design | TEFC |
| Enclosure-ingress-prot | 54 |
| Frame | D112M |
| Frame Size | D112M |
| Frequency | 60 Hz |
| Full Load Amps | 13.9-13.4/6.7A |
|---|---|
| Hp | 37/10 hp |
| Insulation Class | Class F |
| Kva Code | J |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1750 RPM |
| No. Of Speeds | 1 |
| Output Kw | 3.7 kW |
| Phase | 3 |
| Rpm | 1750 RPM |
| Rpm Range | 1700-1800 RPM |
| Service Factor | 1.15 |
| Voltage | 230/460V |
| Height (cm) | 38.42 |
|---|---|
| Length (cm) | 54.93 |
| Width (cm) | 40.96 |
| HS Code | 85015220 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 40.5 |
