| Item | IEC Frame AC Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 9-8.4/4.2A |
| Amps @ 208v | 9A |
| Assembly | B3 |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Break-down Torque | 33.6 lbs.-ft. |
| Class | Stock |
| Code | K |
| Conduit Box Position | B3 |
| Design Code | B |
| Enclosure Design | TEFC |
| Frame | D100L |
| Frame Size | D100L |
| Frequency | 60 Hz |
| Full Load Amps | 9-8.4/4.2A |
| Full Load Torque | 8.88 lbs.-ft. |
| Hp | 11/5 hp |
| Insulation Class | Class F |
| Ip Rating | IP54 |
| Lead | 9#16 |
| Line-line Res. @ 25° C | 3.83 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 22.7 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
|---|---|
| Multiplier | L1 |
| Nameplate Rpm | 1760 RPM |
| No Load Amps | 2.33A |
| No. Of Motor Leads | 9 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 89.5% |
| Output Kw | 2.2 kW |
| Phase | 3 |
| Proprietary | No |
| Pull-up Torque | 19.3 lbs.-ft. |
| Revision | C |
| Rpm | 1700-1800 RPM |
| Service Factor | 1.15 |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 32A |
| Temp. Rise @ Rated Load | 40°C |
| Temp. Rise @ S. F. Load | 48°C |
| Type | 3631M |
| Voltage | 208-230/460V |
| Wire Size | 16 AWG |
| Xp Class And Group | None |
| Height (cm) | 33.33 |
|---|---|
| Length (cm) | 49.21 |
| Width (cm) | 34.92 |
| HS Code | 85015220 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 31.95 |
