| Item | Hydraulic Cylinder |
|---|---|
| Base To Advance Port | 3 1/2" |
| Body Material | Steel |
| Center Hole Diameter | 1 49/64" |
| Clevis Eye Mounting Dimension Length | 24.86" |
| Clevis Eye Mounting Dimension M | 2.09" |
| Clevis Eye Mounting Dimension Overall Length | 35.11" |
| Collapsed Height | 20.69" |
| Collar Thread Length | 1.13" |
| Collar Thread Size | 2 3/4"-16 |
| Cylinder Bore | 2 1/2" |
| Cylinder Capacity Advance At 5000 Psi | 24500 lbs. |
| Cylinder Capacity Retract At 5000 Psi | 10750 lbs. |
| Cylinder Type | High Cycle |
| Effective Push Area | 4.91 sq. in. |
| Extended Height | 30.94" |
| Finish | Paint |
| Handle | No |
| Internal Base Thread Length | 1.02" |
| Internal Base Thread Size | 2 3/4"-16 |
|---|---|
| Material | Steel |
| Max. Operating Pressure | 10000 psi |
| Max. Push Capacity | 25 ton. |
| Nominal Capacity | 25 ton. |
| Nominal Stroke Length | 10" |
| Oil Capacity Push | 50.31 cu. in. |
| Outside Dia. | 3.63" |
| Plunger Dia. | 1 22/25" |
| Plunger Outside Thread Size | 1 1/2"-12 |
| Plunger Thread Length | 1" |
| Plunger Thread Size | 1 1/2"-12 |
| Plunger Type | Solid |
| Promotion Restriction | Not Eligible For Promotion |
| Retracted Height | 20.69" |
| Single Acting/double Acting | Double Acting |
| Stroke Length | 10 1/4" |
| Top To Retract Port | 3 1/2" |
| Weighing Capacity | 25 ton. |
| Height (cm) | 60.43 |
|---|---|
| Length (cm) | 10.59 |
| Width (cm) | 10.59 |
| HS Code | 8412210030 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 21.6 |
