Destaco 810151 | 33TV62 | Position Sensor, 5 - 120VAC / VDC Switching Voltage, 500mA

Q: Does Destaco supply water resistant clamp sensors?

Destaco clamps protect against dust, heavy rain &amp; powerful jets of water owing to inductive sensors that are designed in accordance with IP65 standards.

Specifications

Item	Position Sensor
Color	Metallic
Connector	None
Display	LED
Enclosure Material	Metal
Enclosure Type	Metal
For Bore Dia.	Any Size
Function	Reed
Lead Length	9 ft.

Lead Length (ft)	9 ft.
Max. Switching Current	500 mA
Number Of Wires	2
Switching Amps	500 mA
Switching Voltage	5-120V AC/DC
Temp. Range	+14°F to +140°F
Temperature Range (°f)	14°F to 140°F
Type	Tie Rod Mount

Product Details

Destaco 810151 pneumatic position sensor is designed to enhance the functionality of Destaco's pneumatic swing clamps. This Destaco position sensor is used to sense the position of a cylinder piston and features tie rod mounting style. This position sensor can work at temperatures ranging from 14 degrees Fahrenheit to 140 degrees Fahrenheit, at 500mA switching current. Destaco 810151 tie-rod position sensor has a lead length of 9 ft and is equipped with a magnetic ring activated sensor installed on the cylinder piston. Destaco 810151 pneumatic position sensor features an LED for easy set up.

Shipping Information

Height (cm)	10.16
Length (cm)	10.16
Width (cm)	1.27

HS Code	8536507000
Country Of Origin	US
Weight (kg)	0.081

Uses

Destaco 810151 pneumatic position sensor enhances the functionality of Destaco's pneumatic swing clamps, making them adaptable to applications such as securing & molding closures & access doors and sealing chamber doors in the aerospace, automotive and food & packaging industries.

Features

Destaco 810151 pneumatic position sensor is designed to be mounted to cylinders with tie rods.
It is activated by a magnetic ring installed on the clamp's cylinder.
This pneumatic position sensor is incorporated with an LED for easy set up.
Destaco 810151 pneumatic position sensor is IP67 rated for utmost safety and enhanced functionality.
It can handle temperatures ranging from -10 degrees Celsius to 60 degrees Celsius (14 degrees Fahrenheit to 140 degrees Fahrenheit).
This sensor is used to sense the position of a cylinder piston.

Compatible Accessories

Destaco pneumatic swing clamps: Destaco pneumatic swing clamps are designed for clamping workpieces when it is necessary to keep the clamping area free of straps and clamping components, for unrestricted workpiece loading and unloading. These clamps are used for applications that require very low clamping force. An installed magnetic piston makes it easy to view the clamping position and also allows easy unclamping. The position monitoring provides the required information regarding the piston position, but not regarding the clamping arm position. The magnetic piston is monitored using electronic sensors that detect its magnetic field. By adjusting the displacement of the magnetic sensors, the switching points can be continuously adjusted.

Standards and Approvals

Destaco 810151 pneumatic position sensor meets international standards like ISO 14001:2015 & ISO 9001:2015 to ensure environmental health & safety, and efficient performance of the unit.

Installation

Destaco 810151 pneumatic position sensor is mounted to cylinders with tie rods and can be activated by a magnetic ring installed on the clamp's cylinder.

Frequently Asked Questions

What is a pneumatic swing clamp?

Pneumatic swing clamps are non-locking clamps that are suitable for applications which require low clamping force. Additionally, they keep the clamping area free of clamping components and straps for unobstructed & unrestricted workpiece loading and unloading.

How to differentiate between a left hand and right hand swing clamp?

To determine whether a clamp is a left or right hand swing clamp, you need to view the arm from above, during the clamping stroke. Arms moving counter-clockwise are left hand swing, while arms moving clockwise are right hand swing variants.

How do pneumatic swing clamps work?

A pneumatic swing clamp features a double acting, pull type cylinder where a part of the entire stroke is used for screw-on clamping arm, along with swinging the piston.

Does Destaco supply water resistant clamp sensors?

Destaco clamps protect against dust, heavy rain & powerful jets of water owing to inductive sensors that are designed in accordance with IP65 standards.

What does holding capacity mean in terms of clamps?

The holding force or holding capacity represents the clamp's capability to hold down sheet metal or equipment during manufacturing processes.

What accessories do Destaco pneumatic swing clamps require to operate?

Pneumatic swing clamps require spindles (flat tip, swivel foot or hex head), flanges, replacement seal kits, clamping arm adapters and end mounting foot assemblies for proper and smooth functioning.

Which grease is recommended for use with Destaco clamps when rebuilding?

A coupling grease like Mobil XTC should be used when dealing with Destaco mechanical clamps, while the Magnalube G grease is great for use with pneumatic cylinder seals.
