| Item | Draft Inducer |
|---|---|
| Amps | 1A |
| Application | Furnaces |
| Bearings | Ball |
| Construction Material | Metal |
| Cut Out Required | 4 11/16" |
| Cutout Size | 4 11/16" |
| Depth | 5 1/2" , 5 17/32" |
| Enclosure | Open |
| Finish | Aluminized |
| Fits Brand | Fasco, Trane , Trane |
| For Appliance Type | Furnaces |
| For Fuel Type | Natural Gas |
| For Use With | Furnace |
| For Use With Mfr. Model Number | X38040253057 |
| Frequency | 60 Hz |
| Height | 7 21/32" , 7 5/8" |
| Housing Material | Copper |
| Hp | 1/40 hp |
| Includes | Gasket |
| Includes Motor | Yes |
| Includes Mounting Hardware | Yes |
|---|---|
| Material | Steel Copper |
| Max. Motor Hp | 1/40 hp |
| Maximum Inlet Air Temperature | 40°C |
| Maximum Motor Speed | 3000 RPM |
| Motor Type | Shaded Pole |
| Mounting Hardware Included | Yes |
| Nameplate Voltage | 115V AC |
| No. Of Speeds | 1 |
| Oem Replacement | Yes |
| Overall Depth | 5 1/2" |
| Overall Height | 7 5/8" |
| Overall Width | 7" |
| Overload Protection | Automatic |
| Phase | 1 |
| Remarks | Product Used As Direct Oem Replacement Only. Any Other Use Constitutes A Misapplication Which Voids The Warranty And May Create Unsafe Conditions |
| Replacement For Manufacturer Model No. | 7021-8569, X38040253057 |
| Replacement For Mfr. Model No. | 7021-8569, X38040253057 |
| Type | Replacement |
| Width | 7 7/64" , 7" |
| Height (cm) | 20.32 |
|---|---|
| Length (cm) | 24.13 |
| Width (cm) | 22.86 |
| HS Code | 8414599080 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 2.43 |
| Style | Model | Height | Depth | Outlet Width | Outlet Dia. | Voltage | Inlet Dia. | Amps | Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 65475 | 2 1/4" | - | Not Applicable | 1 1/2" | - | - | 0.4A | Steel Copper | $137.34 | |
| B | 82641 | 8 1/2" | 5" | - | - | 208/230V | - | 0.62A | Steel Copper | $637.20 | |
| B | 82999 | 8.688" | 5.766" | - | - | 208/230V | - | 0.64A | Steel Copper | $547.01 | |
| C | 82052 | 5" | 7 1/2" | 1 3/4" | Not Applicable | - | 5" | 1A | Steel | $515.73 | |
| D | 48332 | 5 1/4" | 8 1/2" | Not Applicable | 2 3/8" | - | 1 7/8" | 1.8/1.1A | Plastic Housing | $513.79 | |
| E | 66003 | 6 5/8" | 8 1/4" | 2 1/8" | Not Applicable | - | 4" | 0.92A | Steel | $393.14 | |
| F | 82148 | 6.453" | 7.593" | 1 3/4" | - | 208/230V | - | 0.5A | Steel | $465.11 |
