| Item | Draft Inducer |
|---|---|
| Amps | 0.92A |
| Application | Furnaces |
| Construction Material | Steel |
| Depth | 8 1/4" , 8 5/16" |
| Fits Brand | Amana, Fasco, Goodman, Rotom , Goodman |
| For Fuel Type | Natural Gas |
| For Use With | Furnace |
| For Use With Mfr. Model Number | 11009001, 11009002, 11009003 |
| Frequency | 60 Hz |
| Height | 6 45/64" , 6 5/8" |
| Housing Material | Steel |
| Hp | 1/50 hp |
| Includes Motor | Yes |
| Includes Mounting Hardware | Yes |
| Inlet Dia. | 4" |
| Material | Steel |
| Max. Motor Hp | 1/20 hp |
| Maximum Inlet Air Temperature | 40°C |
|---|---|
| Maximum Motor Speed | 3250 RPM |
| Motor Type | Permanent Split Capacitor |
| Mounting Hardware Included | Yes |
| Nameplate Voltage | 115V AC |
| Outlet Dia. | Not Applicable |
| Outlet Height | 2 1/2" |
| Outlet Shape | Rectangular |
| Outlet Width | 2 1/8" |
| Overall Depth | 8 1/4" |
| Overall Height | 6 5/8" |
| Overall Width | 7" |
| Phase | 1 |
| Replacement For Manufacturer Model No. | 098862-1, 0988621-1, 11009001, 11009002, 11009003, 7021-10272, 7021-7006, 7021-7259, 7021-9064, 7021-9259, 7021-9574, 7021-9924, 702110272, 70219064, 70219259, 70219574, 70219924, D68862-1, R7-RFB129 |
| Replacement For Mfr. Model No. | 098862-1, 0988621-1, 11009001, 11009002, 11009003, 7021-10272, 7021-7006, 7021-7259, 7021-9064, 7021-9259, 7021-9574, 7021-9924, 702110272, 70219064, 70219259, 70219574, 70219924, D68862-1, R7-RFB129 |
| Type | Replacement |
| Width | 7 7/64" , 7" |
| Height (cm) | 22.61 |
|---|---|
| Length (cm) | 23.62 |
| Width (cm) | 22.1 |
| HS Code | 8414599080 |
|---|---|
| Weight (kg) | 3.231 |
| Style | Model | Height | Depth | Outlet Width | Outlet Dia. | Voltage | Inlet Dia. | Amps | Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 65475 | 2 1/4" | - | Not Applicable | 1 1/2" | - | - | 0.4A | Steel Copper | $137.34 | |
| B | 82641 | 8 1/2" | 5" | - | - | 208/230V | - | 0.62A | Steel Copper | $637.20 | |
| C | 82057 | 7 5/8" | 5 1/2" | - | - | - | - | 1A | Steel Copper | $394.07 | |
| B | 82999 | 8.688" | 5.766" | - | - | 208/230V | - | 0.64A | Steel Copper | $547.01 | |
| D | 82052 | 5" | 7 1/2" | 1 3/4" | Not Applicable | - | 5" | 1A | Steel | $515.73 | |
| E | 48332 | 5 1/4" | 8 1/2" | Not Applicable | 2 3/8" | - | 1 7/8" | 1.8/1.1A | Plastic Housing | $513.79 | |
| F | 82148 | 6.453" | 7.593" | 1 3/4" | - | 208/230V | - | 0.5A | Steel | $465.11 |
