| Item | Tap and Die Set |
|---|---|
| 55% Thread Drill Size | #13, #21, #3, #32, #37, 10.2 mm, 11.3 mm, 11.8 mm, 11/32", 27/64", 3.5 mm, 3.6 mm, 3/32", 4.25 mm, 4.4 mm, 5.25 mm, 5.7 mm, 7.1 mm, 7.25 mm, 8.4 mm, 8.9 mm, 9.1 mm, 9/32", D, I, W |
| 65% Thread Drill Size | #23, #34, #38, #5, 10 mm, 10.5 mm, 11 mm, 11.6 mm, 11/32", 13/64", 17/64", 2.3 mm, 3.4 mm, 3.5 mm, 4.15 mm, 4.3 mm, 4.6 mm, 7/32", 8.9 mm, 9/32", C, I, J, P, R, V |
| 75% Thread Drill Size | #21, #25, #36, #7, 10.30 mm, 11.40 mm, 11/32", 2.20 mm, 2.50 mm, 27/64", 3.30 mm, 3.40 mm, 4.20 mm, 4.45 mm, 5.00 mm, 5.45 mm, 5/16", 6.00 mm, 7.00 mm, 8.50 mm, 9.95 mm, F, H, I, U |
| Class Of Fit | Class 2B |
| Cutting Sizes | #4-12 |
| Die Hex Size | 1" |
| Die Material | Carbon Steel , High Speed Steel |
| Die Series | Hanson |
| Die Shape | Hex |
| Die Thread Sizes Included | #10-24 Unc, #10-32 Unf, #12-24 Unc, #4-40 Unc, #6-32 Unc, #8-32 Unc, 1/2"-13 Unc, 1/2"-20 Unf, 1/4"-20 Unc, 1/4"-28 Unf, 1/8"-27 Npt, 1/8"-28 Bsp, 3/8"-16 Unc, 3/8"-24 Unf, 5/16"-18 Unc, 5/16"-24 Unf, 7/16"-14 Unc, 7/16"-20 Unf, M10 x 1.25, M10 x 1.5, M11 x 1.5, M12 x 1.25, M12 x 1.75, M3 x 0.5, M4 x 0.7, M4 x 0.75, M5 x 0.8, M5 x 0.9, M6 x 1, M7 x 1, M8 x 1, M8 x 1.25, M9 x 1, M9 x 1.25 |
| Die Type | Adjustable |
| Dimensions Standard | BSP, Metric, NPT, UNC, UNF |
| Drill Bit Size | #16, #19, #20, #21, #25, #29, #3, #30, #36, #39, #43, #7, #9, 1/4", 13/32", 19/64", 21/64", 25/64", 27/64", 29/64", 3/8", 5/16", 5/32", 5/64", 7/64", B, F, H, I, J, O, Q, R, S, U, Z |
| Features | Self Alignment |
| Finish | Mill |
| Helix Angle | 0° |
| Material | Carbon |
| Max. Die Thread Size | 1/2"-20 |
| Max. Tap Thread Size | 1/2"-13, 1/2"-20 |
| Min. Tap Thread Size | #4-40 |
| Minimum Bore Diameter | 4-40 UNC |
|---|---|
| Number Of Dies In Set | 34 |
| Number Of Pieces | 116 |
| Number Of Taps | 34 |
| Sae Or Metric | Metric, SAE |
| Size/range | #4 to #12, 1/4" to 1/2", 3 mm to 12 mm |
| Sizes | #4 to #12, 1/4" to 1/2", 3 mm to 12 mm |
| Sizes Included | 4-40, 6-32, 8-32, 10-24, 10-32, 12-24, 1/4-20, 1/4-28, 5/16-18, 5/16-24, 3/8-16, 3/8-24, 7/16-14, 7/16-20, 1/2-13, 1/2-20, M3 x 0.5, M4 x 0.7, M4 x 0.75, M5 x 0.8, M5 x 0.9, M6 x 1, M7 x 1, M8 x 1, M8 x 1.25, M9 x 1, M9 x 1.25, M10 x 1.25, M10 x 1.5, M11 x 1.5, M12 x 1.25, M12 x 1.75, 1 |
| Spiral Direction | Neutral |
| Tap Chamfer | Plug, Taper |
| Tap Material | High Speed Steel |
| Tap Series | Hanson Series |
| Tap Sizes Included | #10-24 UNC, #10-32 UNF, #12-24 UNC, #4-40 UNC, #6-32 UNC, #8-32 UNC, 1/2"-13 UNC, 1/2"-20 UNF, 1/4"-20 UNC, 1/4"-28 UNF, 1/8"-27 NPT, 1/8"-28 BSP, 3/8"-16 UNC, 3/8"-24 UNF, 5/16"-18 UNC, 5/16"-24 UNF, 7/16"-14 UNC, 7/16"-20 UNF, M10 x 1.25, M10 x 1.5, M11 x 1.5, M12 x 1.25, M12 x 1.75, M3 x 0.5, M4 x 0.7, M4 x 0.75, M5 x 0.8, M5 x 0.9, M6 x 1, M7 x 1, M8 x 1, M8 x 1.25, M9 x 1, M9 x 1.25 |
| Tap Type | Self Alignment Tap |
| Tap Wrench Number | PTS Die Stock |
| Thread Direction | Right Hand |
| Thread Pitch | 0.5 mm, 0.7 mm, 0.75 mm, 0.8 mm, 0.9 mm, 1 mm, 1.25 mm, 1.5 mm, 1.75 mm |
| Thread Sizes Included | 1/8"-27, #10-24U, #10-32U, #12-24U, #4-40U, #6-32U, #8-32U, 1/2"-13U, 1/2"-20U, 1/4"-20U, 1/4"-28U, 1/8"-28Bsp, 3/8"-16U, 3/8"-24U, 5/16"-18U, 5/16"-24U, 7/16"-14U, 7/16"-20U, M10X1.25, M10X1.5, M11X1.5, M12X1.25, M12X1.75, M3X0.5, M4X0.7, M4X0.75, M5X0.8, M5X0.9, M6X10, M7X10, M8X10, M8X1.25, M9X10, M9X1.25 |
| Thread Standard | BSP, Metric, NC, NF, NPT |
| Thread Type | BSP, Metric, NC, NF, NPT |
| Threads Per Inch | 16, 18, 20, 24, 27, 28, 32, 40, 1, 314 |
| Height (cm) | 7.87 |
|---|---|
| Length (cm) | 51.82 |
| Width (cm) | 34.8 |
| HS Code | 8207406000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 5.481 |
| Style | Model | Die Material | Tap Chamfer | Die Shape | Min. Tap Thread Size | Max. Tap Thread Size | Max. Die Thread Size | Number Of Pieces | Thread Type | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 1835091 | Carbon Steel | Plug, Taper | Hex | 1/8"-27 | 1/2"-13, 1/2"-20 | 1/2"-20 | 40 | NC, NF, NPT | $798.69 | |
| B | 1835092 | Carbon Steel | Plug | Hex | 1/8"-28 | M12 x 1.75 | M12 x 1.75 | 40 | Metric | $811.01 | |
| C | 24614 | Carbon Steel | Plug | Hex | 1/8"-27 | 1/2"-20 | 1/2"-20 | 24 | NC, NF, NPT | $420.67 | |
| D | 24640 | Carbon Steel | Plug | Hex | 1/8"-27 | 3/4"-16 | 3/4"-16 | 53 | NC, NF, NPT | $1,121.90 | |
| E | 97311 | High Speed Steel | Plug | Hex | M14 x 1.25 | M24 x 3 | M24 x 3 | - | Metric | $1,567.94 | |
| F | 23614 | High Speed Steel | Plug | Round | #12-24 | 1/2"-13 | 1/2"-13 | 39 | NC, NF | $612.84 |
