| Item | Roller Chain |
|---|---|
| Chain Number | C2050 |
| Chain Overall Width | 0.878" |
| Connecting End To Center Line | 0.472" |
| Finish | Coated |
| Heavy Series | No |
| Includes | Connecting Link |
| Inside Width | 3/8" |
| Length | 10 ft. |
| Lubrication | SAE 10 To SAE 50 |
| Material | Steel |
| Max. Allowable Load | 970 lbs. |
| Maximum Operating Temperature | 302°F |
| Minimum Operating Temperature | 14°F |
| Number Of Strands | 1 |
| Outside Pin Dia. | 1/5" |
| Overall Length | 10 ft. |
| Overall Width | 0.878" |
| Pin Construction | Riveted Pin |
| Pin Length | 0.878" |
| Pin Link Plate Thickness | 2/25" |
|---|---|
| Pin Outside Diameter | 0.2" |
| Pin Type | Riveted |
| Pitch | 1 1/4" |
| Pitch Type | Double Pitch |
| Plate Height | 0.591" |
| Plate Thickness | 0.08" |
| Resistance Properties | Corrosion Resistant |
| Rivet End To Center Line | 0.406" |
| Roller Chain Standard | ANSI |
| Roller Dia. | 2/5" |
| Roller Diameter | 13/32" |
| Roller Link Plate Height | 0.591" |
| Series | NEPTUNE Series |
| Size | C2050NT |
| Temp. Range | +14°F to +302°F |
| Tensile Strength | 6170 lbf. |
| Weight Per Length | 0.56 lbs.-ft. |
| Width Between Roller Link Plates | 3/8" |
| Working Load Limit | 970 lbs. |
| Height (cm) | 3.81 |
|---|---|
| Length (cm) | 31.24 |
| Width (cm) | 19.05 |
| HS Code | 7315110045 |
|---|---|
| Country Of Origin | JP |
| Weight (kg) | 2.5965 |
| Style | Model | Material | Tensile Strength | Pitch | Type | Breaking Strength | Roller Dia. | Rivet End To Center Line | Roller Link Plate Height | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 25SSRB | Stainless Steel | 26 lbs. | 1/4" | Single Strand | 26 lbs. | 1/8" | 0.15" | 0.23" | $824.99 | |
| A | 35SSRB | Stainless Steel | 60 lbs. | 3/8" | Single Strand | 60 lbs. | 13/64" | 0.238" | 0.354" | $679.64 | |
| B | 60HRB | Steel | 9920 lbf. | 3/4" | Single Strand Heavy | 2200 lbs. | 15/32" | 0.583" | 0.713" | $439.61 | |
| B | 80HRB | Steel | 17640 lbf. | 1" | - | 3630 lbs. | 5/8" | 18/25" | 0.949" | $706.45 | |
| A | 80SSRB | Stainless Steel | 397 lbs. | 1" | - | 397 lbs. | 5/8" | 0.638" | 0.949" | $2,399.89 | |
| C | C2040NEPRB | Steel | 3740 lbf. | 1" | - | - | 0.312" | 0.325" | 0.472" | $519.87 | |
| C | C2060HNEPRB | Steel | 9040 lbf. | 1 1/2" | - | - | 0.469" | 0.573" | 0.677" | $1,076.93 |
