| Item | Inline Centrifugal Duct Fan |
|---|---|
| Airflow @ 0.000 In Sp | 153 CFM |
| Application | General Purpose |
| Bearing Type | Ball |
| Cfm @ 0.000-in. Sp | 153 CFM |
| Cfm @ 0.100-in. Sp | 146 CFM |
| Cfm @ 0.125-in. Sp | 142 CFM |
| Cfm @ 0.200-in. Sp | 136 CFM |
| Cfm @ 0.250-in. Sp | 130 CFM |
| Cfm @ 0.375-in. Sp | 120 CFM |
| Cfm @ 0.400-in. Sp | 116 CFM |
| Cfm @ 0.450-in. Sp | 113 CFM |
| Cfm @ 0.500-in. Sp | 111 CFM |
| Cfm @ 0.600-in. Sp | 106 CFM |
| Cfm @ 0.750-in. Sp | 96 CFM |
| Cfm @ 0.800-in. Sp | 92 CFM |
| Cfm @ 1.000-in. Sp | 80 CFM |
| Cfm @ 1.200-in. Sp | 61 CFM |
| Cfm @ 1.500-in. Sp | 34 CFM |
| Duct Dia. | 4" |
| Fits Duct Dia. | 4" |
| Flange Width | 1" |
| For Fan Type | Dryer Booster Kit |
| Height | 7 5/8" |
| High-efficiency Motor | No |
| Housing Dia. | 9 1/2" |
|---|---|
| Housing Finish | Epoxy Coated |
| Housing Material | Galvanized Metal |
| Includes | (1) Y Fitting, (2) Grilles, Mounting Bracket |
| Inlet And Outlet Dia. | 4" |
| Length | 9 1/2" |
| Max. Amps | 0.7A |
| Max. Inlet Temp. | 140°F |
| Max. Wattage | 84 W |
| Motor Enclosure Design | Totally Enclosed |
| Motor Ip Rating | IP44 |
| Motor Output Power | 84 W |
| Motor Speed | 2880 RPM |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Position | Horizontal/Vertical |
| Nameplate Voltage | 120V AC |
| Number Of Speeds | 1 |
| Overall Dia. | 7 3/4" |
| Overall Height | 7 5/8" |
| Overall Width | 9 1/2" |
| Phase | 1 |
| Speed Control | Yes |
| Speed Control Included | Yes |
| Standards | AMCA, HVI, UL |
| Height (cm) | 35.56 |
|---|---|
| Length (cm) | 35.56 |
| Width (cm) | 35.56 |
| HS Code | 8414596095 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 6.3 |
| Style | Model | Airflow @ 0.000 In Sp | Motor Speed | Height | Duct Dia. | Motor Output Power | Housing Dia. | Inlet And Outlet Dia. | Max. Wattage | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | KIT-PV100X | 153 CFM | 2880 RPM | 7 5/8" | 4" | 84 W | 9 1/2" | 4" | 84 W | $341.89 | |
| B | KIT-PV200X-DV | 402 CFM | 3100 RPM | 8 1/2" | - | - | 13 1/8" | 8" | 130 W | $549.45 | |
| C | PV-100X | 153 CFM | 2880 RPM | 7 5/8" | 4" | 84 W | 9 1/2" | 4" | 84 W | $321.00 | |
| D | PV-125X | 206 CFM | 2745 RPM | 7 5/8" | 5" | 85 W | 9 1/2" | 5" | 85 W | $326.67 | |
| D | PV-150X | 390 CFM | 3075 RPM | 8 1/2" | 6" | 130 W | 13 1/8" | 6" | 130 W | $397.81 | |
| D | PV-200X | 544 CFM | 2930 RPM | 8 1/2" | 8" | 180 W | 13 1/8" | 8" | 180 W | $555.46 | |
| D | PV-250X | 618 CFM | 3045 RPM | 8 1/2" | 10" | 214 W | 13 1/8" | 10" | 214 W | $641.56 |
