| Item | CJ Series Hub |
|---|---|
| Angular Displacement | 2/25" |
| Bore Type | Solid |
| Color | Silver |
| Coupling Type | Jaw |
| Dimension G | 1.1" |
| Dimension Hd | 3.35" |
| Dimension U | 1.77" |
| Distance Between Spider And Hub Face (dimension Cl) | 0.14" |
| Hub Material | Aluminum |
| Hub Type | A |
| Keyway | Without Keyway |
| Keyway Size | No Keyway |
| Length Through Bore | 2 1/5" |
| Max. Angular Displacement (Δ Ka), N=1500 [1/min] | 1.1° |
| Max. Axial Displacement | 0.082" |
| Max. Bore | 1 22/25" |
| Max. Operating Temp. | -50°F to +248°F |
|---|---|
| Max. Radial Displacement | 0.014" |
| Max. Torque | 5480 lbs.-in. |
| Min. Bore | 0.47" |
| Nominal Torque (with 92 Shore A Spider) | 2740 lbs.-in. |
| Normal Temperature Range (with 80 Shore A, 92 Shore A, And 95/98 Shore A Spiders) | -40°F to +212°F |
| Outside Dia. | 4.13" |
| Overall Coupling Length | 3 4/25" |
| Set Screw Style Coupling Location Size | 0.79" |
| Set Screw Thread Size | 5/16"-18 |
| Speed | 5600 RPM |
| Spider Inside Dia. | 2.01" |
| Spider Outside Dia. | 4.13" |
| Spider Thickness (dimension W) | 0.83" |
| Style | Unbored |
| System Of Measurement | Imperial |
| Height (cm) | 11.4 |
|---|---|
| Length (cm) | 8 |
| Width (cm) | 8 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 2.817 |
