| Item | Hydraulic Cylinder |
|---|---|
| Base Bolt Circle Dia. | 4.33" |
| Base Mounting Holes Bolt Circle | 4.33" |
| Base To Advance Port | 1.19" |
| Body Material | Aluminum |
| Bolt Circle Dia. | 4.33" |
| Center Hole Dia. | 3 3/4" |
| Collapsed Height | 7 8/25" |
| Cylinder Bore | 3.74" |
| Cylinder Type | Lightweight |
| Effective Push Area | 10.99 sq. in. |
| Extended Height | 9.29" |
| Finish | Anodized |
| Handle | Yes |
| Includes | Coupler, Dust Cap |
| Material | Aluminum |
| Max. Operating Pressure | 10000 psi |
| Max. Push Capacity | 50 ton. |
|---|---|
| Nominal Capacity | 50 ton. |
| Nominal Stroke Length | 2" |
| Oil Capacity | 21.63 cu. in. |
| Oil Capacity Push | 21.65 cu. in. |
| Optional Tilt Saddle Addition To Collapsed Height | 0.55" |
| Optional Tilt Saddle Dia. | 2 4/5" |
| Outside Dia. | 5 3/25" |
| Plunger Dia. | 3.74" |
| Plunger Type | Solid |
| Promotion Restriction | Not Eligible For Promotion |
| Retracted Height | 7.32" |
| Saddle Max. Tilt Angle | 5° |
| Saddle Protrusion From Plunger | 3/25" |
| Single Acting/double Acting | Single Acting |
| Stroke Length | 1 7/8" |
| Weighing Capacity | 50 ton. |
| Height (cm) | 20.32 |
|---|---|
| Length (cm) | 45.72 |
| Width (cm) | 20.32 |
| HS Code | 8425420000 |
|---|---|
| Country Of Origin | IN |
| Weight (kg) | 8.73 |
