Bussmann DMM-B-44/100 | 361MM2 | Fast Acting Ferrule Fuse, 1000 VAC, 440 mA

Q: What are the factors to consider while choosing this Bussmann DMM-B-44/100 fast-acting ferrule fuse?

Major factors include current &amp; voltage ratings, type of protection, speed, environmental suitability, compliance with standards, compatibility, physical dimensions, ease of installation and expected lifespan.

Q: What safety precautions should I take when installing or replacing this fuse?

Disconnect power before working on the circuit.Wear appropriate PPE, including gloves and safety goggles.Verify circuit de-energisation with a voltage tester.Use the correct fuse type and specifications.Inspect and repair damaged fuse holders.Handle the fuse by the insulated portion.Ensure proper seating in the fuse holder.Tighten connections securely but not excessively.Inspect for unintended shorts after installation.Reconnect power safely and test equipment.Dispose of old fuses following local regulations.

Specifications
Product Details
Shipping Information
Working Mechanism
Features
FAQ′s

Specifications

Item	Fuse
Ac Voltage	1 kV AC
Ac Voltage Rating	1000V AC
Amps	440 mA
Body Material	Melamine
Body Style	Cylindrical
Dc Voltage	1 kV DC , 1V DC
Dc Voltage Rating	1000V DC
Diameter	0.41"
Equivalent Brand And Series	Bussmann Dmm Series
Equivalent Series	DMM
Fuse Protection Type	Fast Blow
Fuse Size	0.46" x 0.41"
Fuse Type	Fast Blow
Indicator Style	Without Indicator

Interrupt Rating	10 kA at 1000V AC/DC
Length	1 3/8"
Mounting Style	Holder
Mounting Type	Holder
Overall Diameter	0.41"
Packaging	Bulk
Product Type	Melamine Ferrule Fuse
Series	DMM-B Series
Speed	Fast Acting
Termination Type	Clip
Type	Ferrule Fuse
Visual Indication	Non Indicating
Voltage	1 kV , 1000V AC/1000V DC
Standards	CE, UL RECOGNIZED FILE E19180

Product Details

Bussmann DMM-B-44/100 fast-acting ferrule fuse opens the electrical circuit in case of overload and short-circuits quickly. This fuse is effective in multi-meters.

Shipping Information

Height (cm)	3.81
Length (cm)	1.17

Width (cm)	1.17
Weight (kg)	0.0675

Working Mechanism

It has a fuse element that has a low melting point.
When an excessive current surge arises, the fuse element heats up due to its resistance.
The fuse element then swiftly melts and breaks the circuit.
This interruption prevents further current flow, shielding connected components from harm.

Features

Bussmann DMM-B-44/100 fast-acting ferrule fuse has melamine tube construction for superior arc-resistant capabilities.
It has nickel-plated end caps to establish a conductive connection with an electrical conductor.
This fuse is available in holder mounting style with clip terminals to facilitate easy installation in cramped spaces.
It has the capability to carry 100% of the rated current (440mA).

Documentation

Certifications

Frequently Asked Questions

How fast does a fuse burn?

Safety fuses are manufactured with specified burn times per 30 cm, such as 60 seconds, implying that a fuse 30 cm long will take 60 seconds to burn.

What is the difference between interrupting rating and the ampere rating?

The interrupting rating is the maximum amount of energy that the device can safely withstand. The ampere rating of a fuse is the amount of current that the fuse will allow to pass before it begins to operate.

What is the significance of the interrupting rating?

Bussmann DMM-B-44/100 fuse's interrupting rating is significant because it is a safety rating. If a device with a low interrupting rating is used in a circuit with a higher available fault current, the device may fail as it attempts to clear the fault, posing a safety hazard.

What are the factors to consider while choosing this Bussmann DMM-B-44/100 fast-acting ferrule fuse?

Major factors include current & voltage ratings, type of protection, speed, environmental suitability, compliance with standards, compatibility, physical dimensions, ease of installation and expected lifespan.
