| Item | General Purpose Motor |
|---|---|
| Ambient Temp. | 40°C |
| Base Indicator | Rigid |
| Bearing-drive-end | 6312 |
| Bearing-opp-drive-end | 6311 |
| Conduit Box Material | Cast Iron |
| Conduit Box Position | F1 |
| Design Code | A |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Efficiency | 94.1% |
| Efficiency @ 100% Load | 94.1% |
| Enclosure Design | TEFC |
| Frame Material | Iron |
| Frame Size | 324T |
| Frequency | 60 Hz |
| Full Load Amps | 39A |
| Hp | 40 hp |
| Insulation Class | Class F |
| Inverter Code | Inverter Ready |
| Kva Code | H |
| Lubrication | Polyrex EM |
|---|---|
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Type | Three Phase |
| Mounting Type | Foot Mounted |
| Nameplate Rpm | 1775 RPM |
| Nema/iec | NEMA |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Overall Length | 30.28" |
| Phase | 3 |
| Power Factor | 82 |
| Pulley Face Code | Standard |
| Rpm | 1775 RPM |
| Rpm Range | 1700-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 2 1/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Synchronous Rpm | 1800 RPM |
| Voltage | 575V |
| Height (cm) | 59.69 |
|---|---|
| Length (cm) | 87.63 |
| Width (cm) | 78.74 |
| HS Code | 85015230 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 254.7 |
