| Item | Vacuum Pump |
|---|---|
| Amps | 11/5.5A |
| Amps Rating | 11/5.5A |
| Application | Chamber Evacuation, Degassing, Freeze Drying, Light Bulb, Neon Sign Manufacturing, Picture Tube Evacuation, Potting, Rice Porosity Test, Vacuum Drying |
| Ballast | Gas, Inhibits Condensation Inside Pump |
| Displacement | 10.6 CFM |
| Filter | Intake, Screens Reduce Possibility Of Foreign Material Entering Pump |
| Filter Type | Screens |
| Finish | Paint |
| Fluid Compatibility | Oil |
| For Chemical Type | Highly Refined Petroleum |
| Free Air Displacement | 10.6 CFM |
| Frequency | 50 Hz |
| Hp | 1 hp |
| Includes | Oil |
| Inlet Size | 13/16" |
| Inlet Type | NPT |
| Maximum Discharge Pressure | 0 mbar |
| Maximum Operating Pressure | 0 psi |
| Maximum Speed | 525 RPM |
|---|---|
| Maximum Vacuum | 0 torr |
| Maximum Viscosity | 339 SUS |
| Npt Inlet | 1" |
| Oil Capacity | 80 oz. |
| Outlet Size | 13/16" |
| Outlet Type | Nw |
| Output Power | 2 1/2 hp |
| Overall Height | 15.37" |
| Overall Length | 19 1/4" |
| Overall Width | 14.12" |
| Phase | 1 |
| Rpm | 525 RPM |
| Runs Dry | No |
| Seal Material | PTFE |
| Thermal Protection | Automatic Reset |
| Tube Inside Dia. | 13/16" |
| Valve Type | Drain |
| Voltage | 115/230V AC |
| Height (cm) | 46.99 |
|---|---|
| Length (cm) | 57.66 |
| Width (cm) | 44.45 |
| HS Code | 8414100000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 76.5 |
| Style | Model | Voltage | Frequency | Rpm | Displacement | Hp | Overall Width | Outlet Size | Overall Height | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 1400B-01 | 115V AC | 60 Hz | 580 RPM | 0.9 CFM | 1/3 hp | 9" | 7/16" | 12.62" | $4,649.04 | |
| B | 1402B-01 | 115/230V AC | 50 Hz | 525 RPM | 5.6 CFM | 1/2 hp | 12" | 13/16" | - | $6,767.60 | |
| C | 1397B-01 | 115/230V | - | 400 RPM | 17.7 CFM | 1 hp | 13 3/4" | 1 3/4"-20 | 18 3/4" | $12,364.51 | |
| D | 1402B-46 | 115/230V AC | 50/60 Hz | 525 RPM | 5.6 CFM | - | 12" | 13/16" | 15" | $7,081.04 | |
| E | 2070B-01 | 115V AC | 50/60 Hz | - | 1.2 CFM | - | 9" | 1/4" | 18" | $18,805.02 | |
| F | 3021-01 | 115V AC | 60 Hz | 1740 RPM | - | - | 5 2/5" | 7/16" | 9 1/5" | $4,271.32 |
