| Item | General Purpose Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps | 146A |
| Assembly/box Mounting | F1, F2 Capable |
| Cc Number | CC004A |
| Code | G |
| Curvepoint | 0.333 |
| Design Code | B |
| Drive End Bearing Size | 318 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 95.8% |
| Efficiency @ 100% | 96.2% |
| Electrical Type | Squirrel Cage, Induction Run |
| Enclosure Type | Tefc |
| Frame | 444TSC |
| Frame Length | 21.17" |
| Frame Material | Rolled Steel |
| Frame Size | 444TSC |
| Frame Suffix | Tsc |
| Frequency | 50/60 Hz |
| Full Load Amps | 163A |
| Hazardous Location | Not Available |
| Hp | 125 hp |
| Insulation Class | Class F |
| Ip Code | 43 |
| Kw | 93 kW |
| Load | 1.15 |
| Lubrication | Standard |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Reversible |
| Motor Type | Squirrel Cage Induction Run |
|---|---|
| Mounting Type | Rigid |
| Nameplate Rpm | 1800/1500 RPM |
| Nema Design | B, G |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 315 |
| Opp. Drive End Bearing Type | Ball |
| Outline | XK2F1SC2-2117 |
| Output Kw | 93 kW |
| Overall Length | 37.74" |
| Packaging | B |
| Paint | Standard |
| Phase | 3 |
| Power Factor | 83.5 |
| Resistance Main | 0.03 ohms |
| Rotation Type | Reversible |
| Rpm | 1785/1486 RPM |
| Service Factor | 1, 1.15 |
| Service Factor Amps | 167A |
| Shaft Dia. | 2 3/8" |
| Shaft Extension | 4 3/4" |
| Shaft Type | TS |
| Speed Range | Not Available |
| Starting Method | Wye Start Delta Run |
| Synchronous Rpm | 1800/1500 RPM |
| Thermal Protection | No Protection |
| Torque | 575 lbs.-ft. |
| Torquepct | 156 |
| Type | TFR |
| Voltage | 460V |
| Winding | L4444016 |
| Height (cm) | 109.22 |
|---|---|
| Length (cm) | 96.52 |
| Width (cm) | 78.74 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 617.4 |
