LOVEJOY 68514411494 Jaw Coupling Spider, SOX/NBR Rubber, L099, L100, AL099, AL100 Coupling Size

Lovejoy 68514411494 jaw coupling spider is designed for torque transmission between two shafts, as well as protecting components from damage by dampening vibrations & shocks. This spider is a mechanical element used for motion control applications. It perfectly responds to temperature regulations, vibration, misalignment, chemicals, space limitation & high speeds and is ideal for the power generation, wastewater, food & beverage, pulp & paper, steel and marine industries.

• Lovejoy C or LC Type coupling hubs are housed with this Lovejoy 68514411494 jaw coupling spider to form a coupling.
• It must be held in place by either a ring or a collar.
• The elastomeric element is loaded between the jaws of the mating hubs. This connected jaw is capable of operating in the same plane, along with the driving hub jaw that is pushed toward the driven hub jaw.
• The legs of the elastomeric Lovejoy 68514411494 jaw coupling spider ensure transmission and can cushion the force between the driven & the driving jaws by being compressed between them.

• Lovejoy 68514411494 jaw coupling spider accommodates angular and parallel shaft misalignment for continuous duty electric motor driven machinery, as well as motion control, tensioning & vibration management applications.
• It has SOX nitrile rubber construction for ensuring excellent abrasion resistance, absorbing shock loads and protection against dirt, oil, sand, grease & moisture.
• It prevents metal to metal contact, ensuring less internal wear and delivering torque up to 417 inch-lb.
• This solid centre, elastomeric insert style spider is suitable for general power transmission applications where the BE dimension (distance between ends of driven and driving shafts) will remain fairly constant and will be capable of affording a suitable gap.
• The black coloured Lovejoy 68514411494 spider offers high dampening capacity & good chemical resistance
• It features 80 Shore A hardness, even under temperatures ranging from -40 degrees to 212 degrees Fahrenheit.

• Lovejoy LC Type Jaw Coupling Hubs: These hubs feature a fail-safe design with no metal to metal contact so that they perform even when the elastomer fails. They are suitable for applications having speeds over 1750 RPM.
• Lovejoy Coupling Collars: C Type and H Type collars provide great torque & bore capacity and feature radially removable elastomeric cushions for ensuring ease-of-maintenance. They have no metal to metal contact, thus eliminating the need for maintenance and providing resistance against dirt, sand, oil, moisture & grease.
