| Item | Transfer Pump |
|---|---|
| Amps | 1.3A |
| Application | For Highly Corrosive Chemicals, Eliminates Seal Caused Friction Loss, Wear, Contamination And Leakage |
| Bearing Type | Thrust |
| Cord Length | 6 ft. |
| Cord Type | 3-conductor SJO |
| Design | Gravity-Feed, Requires The Pump Inlet To Be Lower Than Liquid Level |
| Discharge Pipe Size | 1/2" |
| Discharge Pipe Type | NPT |
| Discharge Port Size | 1/2" |
| Discharge Port Type | NPT |
| Flow Rate @ 1 Ft. | 8.3 GPM |
| Flow Rate @ 15 Ft. | 1.7 GPM |
| Flow Rate @ 3 Ft. | 7.6 GPM |
| Flow Rate @ 6 Ft. | 7.1 GPM |
| Flow Rate @ 9 Ft. | 5.9 GPM |
| Frequency | 60 Hz |
| Full Load Amps | 1.4A |
| Full Load Current | 1.3A |
| Gasket Material | FKM |
| Height | 5 1/5" |
| Housing Material | Glass Filled Polyphenylene |
| Hp | 1/25 hp |
| Impeller Material | Carbon, Glass Filled Polyphenylene Sulfide |
| Inlet Size | 1/2" |
| Inlet Type | MNPT |
| Intake Pipe Size | 1/2" |
| Intake Pipe Type | MNPT |
| Length | 8.3" |
| Liquid Temp. | 200°F |
| Manufacturers Warranty Length | 1 yr. |
| Max. Ambient Temp. | 77°F |
| Max. Discharge Pressure | 7.01 psi |
| Max. Flow Rate | 8.5 GPM |
| Max. Flow Rate @ 15 Ft Of Head | 1.7 GPM |
| Max. Flow Rate @ 15 Ft. | 1.7 GPM |
|---|---|
| Max. Flow Rate @ 3 Ft Of Head | 7.6 GPM |
| Max. Flow Rate @ 6 Ft Of Head | 7.1 GPM |
| Max. Flow Rate @ 60 Hz | 8.5 GPM |
| Max. Flow Rate @ 9 Ft Of Head | 5.9 GPM |
| Max. Fluid Temp. | 200°F |
| Max. Ft. Of Head | 16.2 ft. |
| Max. Head | 16.2 ft. |
| Max. Outlet Pressure | 7.01 psi |
| Max. Specific Gravity | 1.1 |
| Max. Viscosity | 100 SUS |
| Motor Enclosure Design | Open Fan Cooled |
| Motor Mounting Type | Horizontal |
| Motor Type | Shaded Pole |
| Mounting Orientation | Horizontal |
| Outlet Size | 1/2" |
| Outlet Type | NPT |
| Overall Height | 5 1/5" |
| Overall Length | 8.3" |
| Overall Width | 3.9" |
| Phase | 1 |
| Psi | 7 psi |
| Rpm | 3100 RPM |
| Series | MD-HC Series |
| Specific Gravity | 1.1 |
| Suction Port | 1/2" MNPT |
| Temp (f) @ 0 Psig | 200°F |
| Temp (f) @ 10 Psig | 200°F |
| Temp (f) @ 20 Psig | 150°F |
| Temp (f) @ 30 Psig | 150°F |
| Type | With Base |
| Voltage | 115V AC |
| Watts | 94 W |
| Width | 3.9" |
| Height (cm) | 17.02 |
|---|---|
| Length (cm) | 19.3 |
| Width (cm) | 29.21 |
| HS Code | 8413702005 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 2.835 |
| Style | Model | Hp | Voltage | Max. Outlet Pressure | Max. Head | Housing Material | Flow Rate @ 3 Ft. | Flow Rate @ 6 Ft. | Flow Rate @ 9 Ft. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 584604 | 1/8 hp | 115/230V AC | 12.7 psi | 29.3 ft. | Glass Filled Polyphenylene | 19.2 GPM | 18.2 GPM | 17 GPM | $1,141.42 | |
| B | 582603 | 1/10 hp | 115V AC | 10.5 psi | 24.3 ft. | Plastic | 13.5 GPM | 12.8 GPM | 11.8 GPM | $648.29 | |
| C | 586604 | 1/2 hp | 115/230V AC | 22 psi | 51 ft. | Glass Filled Polyphenylene | 39 GPM | 38 GPM | 36.2 GPM | $1,617.30 | |
| D | 585604 | 1/3 hp | 115/230V AC | 18 psi | 40.5 ft. | Glass Filled Polyphenylene | 33 GPM | 31.8 GPM | 30.5 GPM | $1,505.72 | |
| C | 586650 | 1/2 hp | 230/460V AC | 22.1 psi | 51 ft. | - | - | - | - | $1,136.95 |
