| Item | Raceway |
|---|---|
| Amps | 15A |
| Application Sector | Commercial |
| Basic Material | Steel |
| Color | White |
| Cord Length | No Cord Included |
| Enclosure Rating | Dry Interior Locations |
| Enclosure Type | Steel |
| Features | Steel Raceway, Compact Low Profile Design, Full Range Of Fittings, One And Two - Gang Device Boxes |
| Housing Material | Steel |
| Includes | (2) Blank End Fittings, Base Coupling |
| Length | 5 ft. |
| Material | Steel |
| Max. Amps | 15A |
| Mounting Style | Screw Through Base |
| Nema Receptacle Configuration | NEMA 5-15R |
| Number Of Circuits | 1 |
| Number Of Outlets | 5 |
|---|---|
| Number Of Receptacles | 5 |
| Number Of Wire Leads | 3 |
| Optional Entrance Fitting | Blank End Fitting |
| Outlet Center Distance | 12" |
| Overall Height | 3/4" |
| Overall Width | 1 5/16" |
| Power Indicator | No |
| Raceway Height | 3/4" |
| Raceway Width | 1 5/16" |
| Receptacle Type | NEMA 5-15R |
| Series | PLUGMOLD Series |
| Type | Plugmold |
| Voltage | 125V AC |
| Wire Size | #12 Thhn |
| standard | CULUS LISTED |
| Height (cm) | 2.54 |
|---|---|
| Length (cm) | 154.18 |
| Width (cm) | 3.3 |
| HS Code | 8544429000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 1.305 |
| Style | Model | Number Of Outlets | Material | Color | Outlet Center Distance | Housing Material | Amps | Number Of Circuits | Receptacle Type | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | WH20GB306 | 6 | Steel | White | 6" | Steel | 15A | 1 | NEMA 5-15R | $100.89 | |
| B | WH20GB612 | 6 | Steel | White | 12" | Aluminum | 15A | 1 | NEMA 5-15R | $135.99 | |
| C | S20GB306 | 6 | Stainless Steel | Silver | 6" | Stainless Steel | 15A | 1 | NEMA 5-15R | $160.79 | |
| D | S20GB512 | 5 | Steel | Silver | - | Steel | 15A | 1 | NEMA 5-15R | $177.06 | |
| E | V20GB506TRGFI | 10 | Steel | Ivory | 6" | - | 15A | 1 | NEMA 5-15R | - | RFQ
|
| E | V20GB606TRGFI | 11 | Steel | Ivory | 6" | - | 15A | 1 | NEMA 5-15R | - | RFQ
|
| F | V20GB306TRUSB | 5 | Metallic | Ivory | 6" | - | 15A | 1 | NEMA 5-15R | $180.53 |
