| Item | Flange |
|---|---|
| Bearing Material | Polymer |
| Bevel Length | 10 mm |
| Bolt Circle Diameter | 8.5 mm |
| Bore Dia. | 30 mm |
| Dimension A | 90 mm |
| Dimension C | 40 mm |
| Dimension D | 66 mm |
| Dimension E | 8.5 mm |
| Features | High Wear Resistance, Resistance To Dust And Dirt |
| Flange Length | 90 mm |
| Flange Thickness | 8.5 mm |
| Flange Type | Flanged |
| Flange Width | 40 mm |
| For Bearing Insert Type | Ball |
| Maximum Temperature | 130°C |
|---|---|
| Minimum Temperature | -40°C |
| Mount Hole Size | 215.9 mm |
| Mounting Bolt Size | 215.9 mm |
| Mounting Hole Center To Center | 66 mm |
| Mounting Hole Dia. | 8.5 mm |
| Number Of Bolts | 2 |
| Number Of Mounting Holes | 2 |
| Overall Height | 90 mm |
| Overall Length | 10 mm |
| Overall Thickness | 10 mm |
| Overall Width | 40 mm |
| Standards | Rohs Certified |
| Type | Two Bolt |
| Height (cm) | 1.02 |
|---|---|
| Length (cm) | 12.45 |
| Width (cm) | 4.32 |
| HS Code | 8483304040 |
|---|---|
| Country Of Origin | DE |
| Weight (kg) | 0.0135 |
| Style | Model | Bore Dia. | Overall Thickness | Flange Length | Dimension C | Flange Width | Mounting Hole Center To Center | Mounting Hole Dia. | Dimension D | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | GFL-10 | 10 mm | 6 mm | 30 mm | 15 mm | 15 mm | 22 mm | 4.5 mm | 22 mm | $7.81 | |
| A | GFL-12 | 12 mm | 6 mm | 36 mm | 18 mm | 18 mm | 26 mm | 4.5 mm | - | $8.81 | |
| A | GFL-14 | 14 mm | 6 mm | 42 mm | 21 mm | 21 mm | 30 mm | 5.5 mm | 30 mm | $9.39 | |
| A | GFL-16 | 16 mm | 6 mm | 48 mm | 24 mm | 24 mm | 34 mm | 5.5 mm | 34 mm | $9.66 | |
| A | GFL-18 | 18 mm | 6 mm | 54 mm | 27 mm | 27 mm | 39 mm | 6.5 mm | 39 mm | $10.23 | |
| A | GFL-20 | 20 mm | 10 mm | 60 mm | 30 mm | 30 mm | 44 mm | 6.5 mm | 44 mm | $10.81 | |
| A | GFL-25 | 25 mm | 10 mm | 75 mm | 35 mm | 35 mm | 55 mm | 6.5 mm | 55 mm | $13.64 |
