| Item | Pneumatic Swing Clamp |
|---|---|
| Air Connection Size | 1/8" |
| Air Connection Type | NPT |
| Arm Height | 1.44" |
| Arm Length | 2.75" |
| Arm Material | Aluminum |
| Arm Swing Angle | 90° |
| Body Material | Aluminum |
| Body Mounting Type | Mounting Holes |
| Body Thread Length | 3.17" |
| Body Thread Size | 1 3/4"-12 |
| Clamp Arm Length | 2 3/4" |
| Clamping Force | 55 lbs. |
| Cylinder Bore | 1.19" |
| Cylinder Bore Size | 1.19" |
| Holding Capacity | 68 lbs. |
| Includes | Spindle 485203 Al |
| Material | Aluminum |
|---|---|
| Max Air Pressure | 130 psi |
| Max Clamping Force | 55 lbf. |
| Max Vertical Clamp Stroke | 1/2" |
| Max. Input Air Pressure | 130 psi |
| Mounting | Threaded Body |
| Operating Temp. | -14°F to +195°F |
| Operating Temperature - Maximum | 140°F |
| Operating Temperature - Minimum | -14°F |
| Overall Height | 4.86" |
| Overall Width | 2.13" |
| Rotating Stroke | 3/4" |
| Stroke | 1 1/4" |
| Stroke Length | 1.25" |
| Stroke Length During Rotation | 3/4" |
| Swing Direction | Left Hand |
| Vertical Clamp Stroke | 1/2" |
Destaco 8416 pneumatic swing clamp is suitable for holding down workpieces in metalworking facilities. This clamp is designed for light duty clamping applications & features a sensor ready design for accurately sensing the piston location throughout the clamping operation. It has a synthetic spindle tip that securely holds the workpiece in place & prevents slippage.
| Height (cm) | 10.16 |
|---|---|
| Length (cm) | 16.76 |
| Width (cm) | 8.13 |
| HS Code | 8205700090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.612 |
Yes, Raptor Supplies also offers Destaco 8015 right hand swing clamp, in addition to this left hand swing variant.
