DESTACO 8415 Pneumatic Swing Clamp, Aluminium, 68 lb Holding Capacity

Destaco 8415 pneumatic swing clamp features a compact design that makes it adaptable for confined spaces. It is equipped with an arm that rotates at the top of the stroke. The clamp offers lock angle repeatability with unerring accuracy, thereby making clamping on an extremely compact area easily possible. The clamp is used where uninterrupted & rapid access to the clamping station is required and is ideal for fixturing, testing, assembling & welding applications in the automotive and food & packaging industries. Destaco 8415 clamp features a strong hydraulic clamp mechanism, intended to provide quick clamping in secondary manufacturing operations, on both non metallic and metallic products. This double acting, non locking clamp delivers clamping force in direct proportion to inlet pressures and bore sizes and has a shielded piston rod for protection from weld spattering. It ensures quick swing and clamp movement for improved productivity and offers field adjustable swing direction (from left to right) at 90 degrees. The robust, one-piece construction guarantees accurate alignment of internal components and clamping rigidity. This Destaco clamp is incorporated with a pneumatic input cylinder for connecting to a source of compressed air and has internal orifices to prevent cam damage caused by over accelerating the clamp. Destaco 8415 pneumatic swing clamp features a threaded body that enables easy mounting in a tapped or clearance hole using mounting screws and a sensor ready design that allows the unit to accommodate round style sensors. It clamps down on the workpiece with the help of a manually adjustable threaded stud at the end of an air-powered pivoting arm.

Destaco 8415 pneumatic swing clamp offers a broad combination of features, making it adaptable for applications such as fixturing, testing, assembling and welding in the automotive and food & packaging industries.

• Destaco 8415 pneumatic swing clamp features a locking tapered connection that allows 360 degree arm positioning.
• It comes with a tapered piston rod to accommodate the clamping arm.
• Destaco 8415 pneumatic swing clamp is supplied with a spindle to maximise holding force.
• This pneumatic swing clamp is sensor ready for use with round style sensors.
• If you want to order this swing clamp without the clamping arm, simply add -LA suffix to the MPN (for example, 8415-LA).

• Destaco 821513: These Destaco clamping arms are compatible with Destaco 8415 pneumatic swing clamp. They have lightweight aluminium construction for excellent structural rigidity and are equipped with a locking tapered connection that facilitates arm positioning up to 360 degrees.
• Destaco 841550: These Destaco mounting flanges enhance the capabilities of Destaco 8415 threaded pneumatic swing clamp by allowing variable height adjustments, and are suitable for recessed mounting applications.
• Destaco 841560: These replacement seal kits are designed for unobstructed functioning of Destaco 8415 pneumatic swing clamp.

• Destaco 8415 pneumatic swing clamp meets international standards like ISO 14001:2015 & ISO 9001:2015 to ensure environmental health, utmost user safety and efficient performance of the clamp.

• Destaco 8415 pneumatic swing clamp has an imperial threaded body for mounting the unit in a tapped hole or through a clearance hole, with optional mounting screws and flange accessories.
• The through hole allows recessed mounting.
