| Item | Quiet Design Air Circulator |
|---|---|
| Air Flow | 3450/6090/7450 CFM |
| Air Velocity @ 20 Ft. | 700/520/300 FPM |
| Amps | 2.2/1.6/0.6A |
| Assembled | No |
| Assembly Required | Yes |
| Bearing Type | Ball |
| Blade Dia. | 30" |
| Blade Material | Steel |
| Cfm Medium | 6090 CFM |
| Cfm/watt | 30.2 CFM/W |
| Cord Length | 10 ft. |
| Depth | 24" |
| Drive Type | Direct Drive |
| Environmental Applications | Industrial |
| Fan Accessory Style | Quiet Design |
| Fan Cord Length | 10 ft. |
| Fan Housing Material | Steel |
| Fan Mounting Location | Wall |
| Fan Style | Quiet Design |
| Guard Material | Steel |
| Height | 33 1/2" |
| Housing Material | Steel |
| Hz | 60 Hz |
| Includes | Assembly Hardware, Secondary Safety Support Cable, Wall Mounting Bracket |
| Max. Ambient Temp. | 130°F |
| Max. Depth | 24" |
| Mobile/stationary | Stationary |
| Motor Enclosure Design | Totally Enclosed Air Over |
|---|---|
| Motor Hp | 1/4 hp |
| Motor Insulation | Class A |
| Motor Insulation Class | Class A |
| Motor Speed | 1010/860/530 RPM |
| Motor Type | Permanent Split Capacitor |
| Mounting Location | Wall |
| Nema Plug Configuration | 5-15P |
| No. Of Conductors | 3 |
| Number Of Blades | 3 |
| Number Of Speeds | 3 |
| Oscillating | Yes |
| Oscillating/non-oscillating | Oscillating |
| Oscillation | Oscillating |
| Phase | 1 |
| Product Type | Light-Duty Quiet-Design Industrial Fan |
| Quiet-design | Quiet Design |
| Rpm | 1010/860/530 RPM |
| Shaft Dia. | 1/2" |
| Sound Level | 67.9 dBA, 64.4 dBA, 50.3 dBA |
| Standards | Etl |
| Thermal Protection | Automatic |
| Voltage | 115V AC |
| Watts | 245/185/70 W |
| Wheeled Base | Stationary |
| Width | 33 1/2" |
| Wire Guard Finish | Polyester Powder Coat |
| Height (cm) | 19.05 |
|---|---|
| Length (cm) | 109.22 |
| Width (cm) | 91.44 |
| HS Code | 8414596090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 24.075 |
| Style | Model | Blade Dia. | Oscillating/non-oscillating | Motor Hp | Mounting Location | Sound Level | Max. Ambient Temp. | Environmental Applications | Max. Depth | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 2RDZ6 | 24" | Oscillating | 1/4 hp | Pedestal | 69.4 dBA, 65.1 dBA, 48.6 dBA | 130°F | Industrial | 29 1/2" | $637.28 | |
| B | 2RDZ7 | 30" | Oscillating | 1/4 hp | Pedestal | 67.9 dBA, 64.4 dBA, 50.3 dBA | 130°F | Industrial | 29 1/2" | $459.71 | |
| C | 2RDZ8 | 24" | Oscillating | 1/4 hp | Wall | 69.4 dBA, 65.1 dBA, 48.6 dBA | 130°F | Industrial | 24" | $631.94 | |
| D | 20954 | 30" | Non Oscillating | 333/1000 hp | Pedestal | 75 dBA, 69 dBA, 63 dBA | 105°F | Commercial | 13 1/4" | $841.69 | |
| E | 20956 | 30" | Non Oscillating | 1/3 hp | Wall | 75 dBA, 69 dBA, 63 dBA | 105°F | Industrial | 21 3/4" | $806.50 | |
| D | 20955 | 30" | Oscillating | 1/3 hp | Pedestal | 75 dBA, 69 dBA, 63 dBA | 105°F | Industrial | 15 3/4" | $1,094.36 | |
| E | 20957 | 30" | Oscillating | 1/3 hp | Wall | 75 dBA, 69 dBA, 63 dBA | 105°F | Industrial | 21 3/4" | $1,280.77 |
