| Item | Tray Cable |
|---|---|
| Application | Alarm Systems, Audio Systems, Communications, Computer Systems, Control Systems |
| Cable Length | 1000 ft. |
| Cable Type | Power Limited |
| Color | Black, Gray, Red, White |
| Conductor Gauge | 22 AWG |
| Conductor Size | 22 AWG |
| Conductor Type | Stranded |
| Fire Rating | Commercial |
| Fire Rating (data Cable) | Commercial |
| Insulation Material | PVC |
| Jacket Color | Gray |
| Jacket Material | PVC |
| Length | 1000 ft. |
| Maximum Operating Temperature | 221°F |
| Maximum Voltage Rating | 300V |
| Minimum Operating Temperature | -4°F |
| Nec Article | 725 PLTC |
| Nec Article And Type | 725 PLTC |
| Nominal Outside Dia. | 0.199" |
| Number Of Conductors | 3 |
|---|---|
| Number Of Pairs | 0 |
| Number Of Strands | 7 |
| Outside Dia. | 1/5" |
| Outside Diameter | 0.2" |
| Package Type | Reel In A Box |
| Package Type (data Cable) | Reel In A Box |
| Pairing | Unpaired |
| Power Limited | Power Limited |
| Product Type | Communication Cable |
| Shielded | Shielded |
| Shielded / Unshielded | Shielded |
| Shielding Material | 100% Aluminum, 100% Polyester Flexfoil |
| Solid/stranded | Stranded |
| Spool/coil Length | 1000 ft. |
| Stranded / Solid | Stranded |
| Suggested Voltage Rating (data Cable) | 300V |
| Temp. Range | -4°F to +221°F |
| Voltage | 300V |
| Standards | CE 2006/95/EC, NEC ARTICLE 725, NEC/CEC TYPE CMG, ROHS COMPLIANT, UL 70, 000 BTU VERTICAL TRAY FLAME TEST |
| Height (cm) | 28.19 |
|---|---|
| Length (cm) | 27.69 |
| Width (cm) | 27.94 |
| HS Code | 8544493080 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 11.025 |
| Style | Model | Shielded | Number Of Conductors | Number Of Strands | Cable Length | Conductor Size | Spool/coil Length | Shielded / Unshielded | Color | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | C0454A.38.10 | Shielded | 2 | 16 | 500 ft. | 18 AWG | 500 ft. | Shielded | - | $329.39 | |
| A | C0456A.38.10 | Shielded | 2 | 19 | 500 ft. | 16 AWG | 500 ft. | Shielded | Gray | $418.72 | |
| A | C0450A.41.10 | Shielded | 2 | 7 | 1000 ft. | 22 AWG | 1000 ft. | Shielded | Gray | $488.24 | |
| A | C0452A.41.10 | Shielded | 2 | 7 | 1000 ft. | 20 AWG | 1000 ft. | Shielded | Gray | $569.87 | |
| A | C0453A.41.10 | Shielded | 3 | 7 | 1000 ft. | 20 AWG | 1000 ft. | Shielded | Gray | $653.45 | |
| A | C0454A.41.10 | Shielded | 2 | 16 | 1000 ft. | 18 AWG | 1000 ft. | Shielded | Gray | $896.75 | |
| A | C0455A.41.10 | Shielded | 3 | 16 | 1000 ft. | 18 AWG | 1000 ft. | Shielded | Gray | $1,088.32 |
