| Item | Water Circulator Motor |
|---|---|
| Compatible With Brand | Bell And Gossett |
| Compatible With Grainger Part No. | 5YN73, 5YN77 |
| Compatible With Mfr. Part No. | 617T, 625T |
| Compatible With Pump Type | In Line Circulating Pumps |
| Compatible With Series | W69035, W69232, W69233, W69237 |
| Compatible With Series Family | BE627S, BE627T, E617S, E617T, E625, E625S, E627S, E627T |
| Conduit Box Position | F1 |
| Frame | NEMA 56 |
| Frame Material | Cast Iron |
| Frequency | 60 Hz |
| Full Load Amps | 4.8A |
| Hp | 1 1/2 hp |
| Max. Ambient Temp. | 104°F |
| Maximum Rpm | 1725 RPM |
| Min. Ambient Temp. | 32°F |
|---|---|
| Motor Application | Water Circulators |
| Motor Enclosure Design | Open Dripproof |
| Motor Shaft Rotation | Clockwise Lead End |
| Motor Type | Three Phase |
| Mounting Type | C Face, Footless |
| Nameplate Rpm | 1725 RPM |
| Nameplate Voltage | 208-230/460V AC |
| No. Of Speeds | 1 |
| Phase | 3 |
| Pump Type | In-Line Circulating Pump |
| Series | W69035, W69232, W69233, W69237 Series |
| Thermal Protection | None |
| Voltage | 208-240/460V AC |
| Motor Thermal Protection | None |
| Height (cm) | 33.53 |
|---|---|
| Length (cm) | 41.15 |
| Width (cm) | 29.97 |
| HS Code | 8501514040 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 12.9375 |
| Style | Model | Voltage | Hp | Frame | Frequency | Full Load Amps | Motor Shaft Rotation | Motor Type | Phase | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 111040 | 115V AC | 1/4 hp | B&G FRAME 6" | 60 Hz | 3A | Counter Clockwise Lead End | Split Phase | 1 | $1,833.51 | |
| A | 111042 | 115/240V AC | 1/3 hp | B&G FRAME 6" | 60 Hz | 4.2A | Counter Clockwise | Split Phase | 1 | $2,132.88 | |
| B | 111044 | 115/230V AC | 1/2 hp | B&G FRAME 6" | 60 Hz | 5.2A | Clockwise Lead End | Split Phase | 1 | $3,264.11 | |
| B | 111047 | 115/240V AC | 3/4 hp | B&G FRAME 6" | 60 Hz | 7A | Clockwise Lead End | Split Phase | 1 | $3,885.98 | |
| C | 169232 | 115/208-230V AC | 1 3/4 hp | NEMA 48 | 50/60 Hz | 9.8/4.5A | Clockwise Lead End | Split Phase | 1 | $4,273.71 | |
| A | 111034 | 115V AC | 1/12 hp | B&G FRAME 5" | 60 Hz | 1.7A | Counter Clockwise Lead End | Split Phase | 1 | $762.97 | |
| A | 111031 | 115V AC | 1/6 hp | B&G FRAME 5" | 60 Hz | 1.9A | Counter Clockwise Lead End | Split Phase | 1 | $987.87 |
