| Item | Water Circulator Motor |
|---|---|
| Body Dia. | 5" |
| Compatible With Brand | Bell And Gossett |
| Compatible With Grainger Part No. | 4RD16, 4RD17 |
| Compatible With Manufacturer Model Number | 106189, 100 BNFI SERIES |
| Compatible With Mfr. Part No. | 106189, SERIES 100 BNFI |
| Compatible With Pump Type | In Line Circulating Pumps |
| Compatible With Series | W06189, W06197(Obs), W06197Lf |
| Compatible With Series Family | 100 Series |
| Frame | B&G FRAME 5" |
| Frame Material | Cast Iron |
| Frequency | 60 Hz |
| Full Load Amps | 1.7A |
| Hp | 1/12 hp |
| Max. Ambient Temp. | 104°F |
| Maximum Rpm | 1725 RPM |
|---|---|
| Min. Ambient Temp. | 32°F |
| Motor Application | Water Circulators |
| Motor Enclosure Design | Open Dripproof |
| Motor Shaft Rotation | Counter Clockwise Lead End |
| Motor Thermal Protection | Auto |
| Motor Type | Split Phase |
| Mounting Type | Cradle Base |
| Nameplate Rpm | 1725 RPM |
| No. Of Speeds | 1 |
| Phase | 1 |
| Pump Type | In-Line Circulating Pump |
| Series | W06189, W06197(OBS), W06197LF Series |
| Thermal Protection | Automatic |
| Voltage | 115V AC |
| Height (cm) | 23.37 |
|---|---|
| Length (cm) | 25.4 |
| Width (cm) | 23.11 |
| HS Code | 8501404020 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 6.75 |
| Style | Model | Voltage | Hp | Frame | Frequency | Full Load Amps | Motor Shaft Rotation | Motor Type | Phase | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 111040 | 115V AC | 1/4 hp | B&G FRAME 6" | 60 Hz | 3A | Counter Clockwise Lead End | Split Phase | 1 | $1,833.51 | |
| A | 111042 | 115/240V AC | 1/3 hp | B&G FRAME 6" | 60 Hz | 4.2A | Counter Clockwise | Split Phase | 1 | $2,132.88 | |
| B | 111044 | 115/230V AC | 1/2 hp | B&G FRAME 6" | 60 Hz | 5.2A | Clockwise Lead End | Split Phase | 1 | $3,264.11 | |
| B | 111047 | 115/240V AC | 3/4 hp | B&G FRAME 6" | 60 Hz | 7A | Clockwise Lead End | Split Phase | 1 | $3,885.98 | |
| C | 169232 | 115/208-230V AC | 1 3/4 hp | NEMA 48 | 50/60 Hz | 9.8/4.5A | Clockwise Lead End | Split Phase | 1 | $4,273.71 | |
| D | 169237 | 208-240/460V AC | 1 1/2 hp | NEMA 56 | 60 Hz | 4.8A | Clockwise Lead End | Three Phase | 3 | $3,443.40 | |
| A | 111031 | 115V AC | 1/6 hp | B&G FRAME 5" | 60 Hz | 1.9A | Counter Clockwise Lead End | Split Phase | 1 | $987.87 |
