| Item | IEC Frame AC Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 2.8/1.4A |
| Amps @ 208v | 3.4A |
| Base Type | Not Applicable |
| Break-down Torque | 6.6 lbs.-ft. |
| Class | Stock |
| Code | L |
| Conduit Box Position | F2 |
| Design Code | B |
| Enclosure Design | TEFC |
| Frame | D71C |
| Frame Size | D71C |
| Frequency | 60 Hz |
| Full Load Amps | 2.8/1.4A |
| Full Load Torque | 1.1 lbs.-ft. |
| Hp | 1/26 hp |
| Insulation Class | Class B |
| Ip Rating | IP54 |
| Lead | 9#18 |
| Line-line Res. @ 25° C | 17 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 6.4 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | Rigid Base |
| Multiplier | K |
|---|---|
| Nameplate Rpm | 3450 RPM |
| No Load Amps | 0.75A |
| No. Of Motor Leads | 9 |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 75.5% |
| Output Kw | 0.56 kW |
| Phase | 3 |
| Power Factor | 78 |
| Proprietary | No |
| Pull-up Torque | 4.4 lbs.-ft. |
| Revision | X |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.25 |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 10.8A |
| Temp. Rise @ Rated Load | 53°C |
| Temp. Rise @ S. F. Load | 66°C |
| Type | 3328M |
| Voltage | 230/460V |
| Wire Size | 18 AWG |
| Base Indicator | None |
| Height (cm) | 23.81 |
|---|---|
| Length (cm) | 35.09 |
| Width (cm) | 27.47 |
| HS Code | 85015100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 11.7 |
