| Item | IEC Frame AC Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 2.6-2.4/1.2A |
| Amps @ 208v | 2.6A |
| Base Type | Not Applicable |
| Break-down Torque | 6.89 lbs.-ft. |
| Class | Stock |
| Conduit Box Position | F2 |
| Design Code | B |
| Enclosure Design | TEFC |
| Frame | D71C |
| Frame Size | D71C |
| Frequency | 60 Hz |
| Full Load Amps | 2.6-2.4/1.2A |
| Full Load Torque | 1.54 lbs.-ft. |
| Hp | 37/100 hp |
| Insulation Class | Class B |
| Ip Rating | IP54 |
| Lead | 9#18 |
| Line-line Res. @ 25° C | 29.2 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 6.55 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | Rigid Base |
| Multiplier | K |
|---|---|
| Nameplate Rpm | 1725 RPM |
| No Load Amps | 1.21A |
| No. Of Motor Leads | 9 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 71% |
| Output Kw | 0.37 kW |
| Phase | 3 |
| Power Factor | 54 |
| Proprietary | No |
| Pull-up Torque | 5.62 lbs.-ft. |
| Revision | AB |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 6.27A |
| Temp. Rise @ Rated Load | 83°C |
| Type | 3320M |
| Voltage | 208-230/460V |
| Wire Size | 18 AWG |
| Base Indicator | None |
| Height (cm) | 23.81 |
|---|---|
| Length (cm) | 35.09 |
| Width (cm) | 27.47 |
| HS Code | 85015100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 9.9 |
