| Item | General Purpose Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 6/3A |
| Amps @ 208v | 3.6A |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Break-down Torque | 2.95 lbs.-ft. |
| Cc Number | CC031A |
| Code | L |
| Conduit Box Position | F1 |
| Design Code | N |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Efficiency | 60% |
| Enclosure Design | TEFC |
| Frame | 48 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 6/3A |
| Full Load Torque | 1 lbs.-ft. |
| Hp | 1/3 hp |
| Hz | 60 Hz |
| Includes | Conduit Box |
| Ins. Class | Class B |
| Insulation Class | Class B |
| Inverter Code | Not Inverter |
| Lead | 6#18 |
| Length Less Shaft | 9 1/4" |
| Line-line Res. @ 25° C | 1.5 ohms A Ph/4.81 ohms B Ph |
| Locked-rotor Torque | 3.6 lbs.-ft. |
| Manufacturers Warranty Length | 2 yrs. |
| Max. Ambient Temp. | 104°F |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Steel |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.35 |
| Motor Shaft Design | Flat |
|---|---|
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Capacitor Start |
| Mounting Type | Foot Mounted |
| Multiplier | K |
| Nameplate Rpm | 1725 RPM |
| Nema Design | N |
| Nema/iec | NEMA |
| No Load Amps | 5.2A |
| No. Of Motor Leads | 6 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 60% |
| Overall Length | 10.72" |
| Phase | 1 |
| Power Factor | 60 |
| Proprietary | No |
| Pull-up Torque | 2.55 lbs.-ft. |
| Pulley Face Code | Standard |
| Revision | X |
| Rpm | 1700-1800 RPM |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.35 |
| Shaft Dia. | 1/2" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Length | 1 1/2" |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 26A |
| Synchronous Rpm | 1800 RPM |
| Temp. Rise @ Rated Load | 68°C |
| Temp. Rise @ S. F. Load | 81°C |
| Thermal Protection | None |
| Type | 3414L |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/230V |
| Warranty | 2 yrs. |
| Wire Size | 18 AWG |
| Motor Thermal Protection | None |
| Xp Class And Group | None |
| Height (cm) | 23.81 |
|---|---|
| Length (cm) | 35.09 |
| Width (cm) | 27.47 |
| HS Code | 85013100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 9.9 |
| Style | Model | Voltage | Hp | Full Load Amps | Service Factor | Nameplate Rpm | Motor Type | Mounting Type | Frame | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | EL3403 | 115/230V | 1/4 hp | 2.5/1.25A | 1.35 | 1745 RPM | Capacitor Start | Foot Mounted | 48 | $1,008.97 | |
| A | EL3405 | 115/208-230V | 1/3 hp | 3.2/1.7-1.6A | 1.35 | 3450 RPM | Capacitor Start/Run | Rigid Base | 48 | $565.56 | |
| A | EL3501 | 115/230V | 1/3 hp | 3.2/1.6A | 1.35 | 1740 RPM | Capacitor Start | Foot Mounted | 56 | $1,124.44 | |
| A | EL3503 | 115/230V | 1/2 hp | 4.9/2.5A | 1.25 | 3450 RPM | Capacitor Start | Foot Mounted | 56 | $1,142.18 | |
| A | EL3504 | 115/230V | 1/2 hp | 4.6/2.3A | 1.25 | 1745 RPM | Capacitor Start | Foot Mounted | 56 | $1,292.56 | |
| A | EL3506 | 115/230V | 3/4 hp | 7.8/3.9A | 1.25 | 3450 RPM | Capacitor Start | Foot Mounted | 56 | $1,383.71 | |
| A | EL3507 | 115/208-230V | 3/4 hp | 6.3/3.4-3.15A | 1.25 | 1755 RPM | Capacitor Start | Foot Mounted | 56 | $1,471.89 |
