| Item | Swing Flex Check Valve |
|---|---|
| 3-a Compliance | Not Rated |
| Ansi Flange Class | Class 125 |
| Body Material | Ductile Iron |
| Check Mechanism | Swing |
| Connection Size - Side 1 | 2" |
| Connection Size - Side 2 | 2" |
| Connection Type | Flange x Flange |
| Connection Type - Side 1 | Flange |
| Connection Type - Side 2 | Flange |
| Cracking Pressure | 0.25 psi |
| Disc Material | Steel |
| Flow Rate | 95 GPM |
| For Media | Drinking Water |
| Length | 8" |
| Max. Flow Rate | 110 GPM |
| Max. Pressure (cwp) | 250 psi |
| Max. Pressure (steam) | Not Rated |
| Max. Temp. | -70°F to +215°F |
| Max. Water Pressure | 250 psi |
| Media Temp. Range | 33°F to 200°F |
|---|---|
| Media Temperature Range | 33°F to 200°F |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Position | Horizontal |
| Nsf Certifications For Food And Drinking Water | NSF 61 |
| Operating Temperature - Maximum | 200°F |
| Operating Temperature - Minimum | 33°F |
| Overall Length | 8" |
| Pipe Size | 2" |
| Seal Material | Buna-N |
| Seat Material | Buna N |
| Silent Check | Standard |
| Size | 2" |
| Standards | Nsf/Ansi 372 |
| Temp. Range | -70°F to +215°F |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Inline |
| Valve Series | Series 500A |
| Width | 6" |
| Height (cm) | 27.43 |
|---|---|
| Length (cm) | 19.56 |
| Width (cm) | 18.8 |
| HS Code | 8481302010 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 11.727 |
| Style | Model | Pipe Size | Flow Rate | Max. Flow Rate | Body Material | Connection Type | Max. Temp. | Seat Material | Cracking Pressure | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 525A | 2 1/2" | 155 GPM | 220 GPM | Ductile Iron | Flange x Flange | -70°F to +215°F | Buna N | 0.25 psi | $1,310.68 | |
| A | 503A | - | 225 GPM | 300 GPM | Ductile Iron | Flange x Flange | -70°F to +215°F | Buna N | 0.25 psi | $1,514.98 | |
| A | 504A | - | 440 GPM | 500 GPM | Ductile Iron | Flange x Flange | -70°F to +215°F | Buna N | 0.25 psi | $1,614.25 | |
| A | 506A | 6" | 1040 GPM | 1000 GPM | Ductile Iron | Flange x Flange | -70°F to +215°F | Buna N | 0.25 psi | $2,726.10 | |
| A | 508A | - | 1900 GPM | 2250 GPM | Ductile Iron | Flange x Flange | -70°F to +215°F | Buna N | 0.25 psi | $4,296.10 | |
| A | 510A | - | 3050 GPM | 2500 GPM | Ductile Iron | Flange x Flange | -70°F to +215°F | Buna N | 0.25 psi | $7,072.96 | |
| A | 512A | - | 4600 GPM | 4000 GPM | Ductile Iron | Flange x Flange | -70°F to +215°F | Buna N | 0.25 psi | $9,552.50 |
