| Item | Circuit Breaker |
|---|---|
| Ac Voltage Rating | 600V AC |
| Amps | 300A |
| Circuit Breaker Application | HACR Rated |
| Circuit Breaker Type | Standard |
| Component Type | Circuit Breaker |
| Dc Voltage | 250V DC |
| Depth | 5 4/5" , 5.84" |
| Electrical Connection | Lugs, Load, Line |
| Height | 11" |
| High Amp Trip Setting | 3000A |
| Line Rated Amps | 300A |
| Low Amp Trip Setting | 1500A |
| Magnetic Hold Amps | 1500A |
| Magnetic Tripping Amps | 3000A |
| Max. Air Rating | Not Rated |
|---|---|
| Min. Wire Size | 1 AWG |
| Mounting | Free Standing |
| Mounting Mode | Unit Mount |
| No. Of Poles | 3 |
| Number Of Poles | 3 |
| Phase | 3 |
| Phase Connection | ABC |
| Returnability | Yes |
| Terminal Connection Type | Lug |
| Tightening Torque | 115.06 lbf.in. @ 0.07 sq. in. to 0.5 sq. in. @ 1 AWG to 600 kcmil, 115.06 lbf.in. @ 0.07 sq. in. to 0.2 sq. in. @ 1 AWG to 250 kcmil |
| Trip Type | Thermal Magnetic |
| Trip Unit Technology | Thermal-Magnetic |
| Width | 6" |
| Warranty | 18 Months |
| Height (cm) | 27.94 |
|---|---|
| Length (cm) | 14.83 |
| Width (cm) | 15.24 |
| HS Code | 8536200040 |
|---|---|
| Weight (kg) | 6.795 |
