| Item | Contactor |
|---|---|
| Action Type | Non Reversing |
| Coil Voltage | 24V AC |
| Component Type | Definite Purpose Contactor |
| Contactor Frame Size | Standard |
| Contactor Type | Definite Purpose |
| Control Circuit Voltage | 24V AC |
| Depth | 3 3/25" |
| Electrical Connection | Box Lugs, Quick Connect Terminals |
| Enclosure Type | Open |
| Frequency | 50/60 Hz |
| Full Load Current - Resistive | 50A |
| Height | 4" |
| Horsepower @ Three Phase - 240v Ac | 10 hp |
| Horsepower @ Three Phase - 600v Ac | 50 hp |
| Hp @ 1 Phase - 120v | 3 hp |
| Hp @ 1 Phase - 230v | 7 1/2 hp |
| Hp @ 3 Phase - 208v | 2.16 hp |
| Hp @ 3 Phase - 230v | 10 hp |
| Hp @ 3 Phase - 480v | 20 hp |
| Hp @ 3 Phase - 575v | 20 hp |
| Hp @ Single Phase - 240v Ac | 7 1/2 hp |
| Inductive Full Load Amps | 40A |
| Line Rated Amps | 40A |
| Locked Rotor Load | 160A @ 575V AC, 200A @ 460V AC, 240A @ 277V AC |
| Locked Rotor Rated Amps | 240A At 277V AC, 200A At 460V AC, 160A At 575V AC |
|---|---|
| Main Pole Contact Form | 3NO |
| Max. Hp Rating | 3 hp @ 115V AC, 7.5 hp @ 230V AC, 10 hp @ 230V AC, 20 hp @ 460V AC, 25 hp @ 575V AC |
| Maximum Voltage Rating | 600V AC |
| Mounting Hole Diameter | 1/5" |
| Mounting Hole Distance - Height | 3.25" |
| Mounting Hole Distance - Width | 2" |
| Nema Enclosure Rating | No Enclosure |
| No. Of Poles | 3 |
| Nominal Coil Voltage @ 60hz | 24V AC |
| Number Of Poles | 3 |
| Overall Depth | 3" |
| Overall Height | 3 3/4" |
| Overall Width | 2.37" |
| Phase | Three |
| Pole Contact Composition | 3 NO , NO |
| Rated Operational Voltage | 600V |
| Resistive Full Load Amps | 50A |
| Returnability | Yes |
| Reversing Capability | Non-reversing |
| Series | 8910 Series TYPE DPA Series |
| Width | 2 1/2" |
| Wire Termination Type | Box Lug, Quick Disconnect |
| Standards | CSA, ROHS, UL LISTED |
| Warranty | 18 Months |
| Height (cm) | 7.87 |
|---|---|
| Length (cm) | 10.16 |
| Width (cm) | 6.35 |
| HS Code | 8536904000 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 0.468 |
| Style | Model | Number Of Poles | Phase | Hp @ 3 Phase - 480v | Hp @ 3 Phase - 240v | Coil Voltage | Inductive Full Load Amps | Resistive Full Load Amps | Depth | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 8910DP31V02 | 1 | Single | - | - | 120V AC | 30A | 40A | 2.22" | $79.71 | |
| A | 8910DP31V14 | 1 | Single | - | - | 24V AC | 30A | 40A | 2.22" | $79.71 | |
| B | 8910DPA62V14 | 2 | 1 | 30 hp | - | 24V AC | 60A | 75A | 3.67" | $285.20 | |
| C | 8910DP12V09 | 2 | 1 | - | - | 208/240V AC | 20A | 30A | 2.22" | $66.43 | |
| D | 8910DPA63V09 | 3 | Three | 30 hp | - | 220/208-240V AC | 60A | 75A | 3.67" | $315.16 | |
| D | 8910DPA93V02 | 3 | Three | 50 hp | - | 120V AC | 90A | 120A | 4.37" | $513.44 | |
| D | 8910DPA93V09 | 3 | Three | 50 hp | - | 220/208-240V AC | 90A | 120A | 4.37" | $513.44 |
