| Item | Hydraulic Coupler Nipple |
|---|---|
| Body Material | Stainless Steel |
| Connection Type | NPSF |
| Coupler Finish | Plain |
| Coupling Component | Plug |
| Coupling Locking Type | Sleeve |
| Coupling Size | 1" |
| Finish | Plain |
| Finish/coating | Plain |
| Fitting Type | Female NPSF |
| Flow Rate | 35 GPM |
| Gender | Female |
| Grade | Grade 316 |
| Hose Fitting Gender | Female |
| Includes Bearing | No |
| Includes Shut Off | Yes |
| Includes Valve | Yes |
| Locking Mechanism | Ball |
|---|---|
| Locking Type | Sleeve |
| Max. Flow Rate | 132.5 LPM |
| Max. Outside Dia. | 2 11/64" |
| Max. Pressure | 2000 psi |
| Max. Working Pressure @ 70 F | 2000 psi |
| Overall Length | 2 35/64" |
| Parker Interchange | SVHN16-16FV |
| Quick Coupler Type | Hydraulic Coupler Nipple |
| Seal Material | Fluorocarbon |
| Series | H Series |
| Shut Off | Yes |
| Sleeve Material | Stainless Steel |
| Sleeve Material Grade | Grade 316 |
| Valve Design | Poppet |
| Valve Type | Poppet |
| Height (cm) | 8.89 |
|---|---|
| Length (cm) | 13.97 |
| Width (cm) | 10.8 |
| HS Code | 8481803090 |
|---|---|
| Weight (kg) | 0.4275 |
| Style | Model | Body Material | Coupling Size | Valve Type | Locking Type | Connection Type | Max. Pressure | Shut Off | Sleeve Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | SVHN8-8M | Stainless Steel | 1/2" | Poppet | Push To Connect | NPT | 3750 psi | Yes | Stainless Steel | $354.44 | |
| A | SVHN8-8MV | Stainless Steel | 1/2" | Poppet | Ball | NPT | 3750 psi | Yes | Stainless Steel | $405.00 | |
| B | BVHN12-12F | Brass | 3/4" | Poppet | Ball | NPTF | 2000 psi | Yes | Brass | $109.19 | |
| B | BVHN12-12FV | Brass | 3/4" | Poppet | Ball | NPTF | 2000 psi | Yes | Brass | $127.74 | |
| C | BVHN12-12M | Brass | 3/4" | Poppet | Ball | NPT | 2000 psi | Yes | Brass | $126.76 | |
| B | BVHN16-16F | Brass | 1" | Poppet | Ball | NPTF | 1750 psi | Yes | Brass | $209.79 | |
| B | BVHN16-16FV | Brass | 1" | Poppet | Ball | NPTF | 1750 psi | Yes | Brass | $244.67 |
