| Item | Contactor |
|---|---|
| Action Type | Reversing |
| Auxiliary Contacts Included | 1NO/1NC |
| Coil Voltage | 120V AC |
| Contactor Style | NEMA |
| Contactor Type | NEMA |
| Control Circuit | Common Control Circuit |
| Depth | 3.62" |
| Electrical Connection | Screw Clamp Terminals |
| Embedded Surge Suppressor | No |
| Enclosure Nema Rating | No Enclosure |
| Enclosure Type | Open |
| Full Load Amps | 9A |
| Full Load Inductive Amps | 9A |
| Height | 3.9" |
| Horsepower @ Single Phase | 1 hp |
| Horsepower @ Single Phase - 120v Ac | 1/3 hp |
| Horsepower @ Single Phase - 240v Ac | 1 hp |
| Horsepower @ Three Phase - 208v Ac | 1 1/2 hp |
| Horsepower @ Three Phase - 600v Ac | 2 hp |
| Hp @ 1 Phase - 120v | 1/3 hp |
| Hp @ 1 Phase - 230v | 1 hp |
| Hp @ 1 Phase - 240v | 1 hp |
| Hp @ 3 Phase - 208v | 1 1/2 hp |
| Hp @ 3 Phase - 230v | 1 1/2 hp |
| Hp @ 3 Phase - 240v | 1 1/2 hp |
| Hp @ 3 Phase - 480v | 2 hp |
|---|---|
| Hp @ 3 Phase - 575v | 2 hp |
| Hz | 50/60 Hz |
| Includes Auxiliary Contacts | Yes |
| Inductive Full Load Amps | 9A |
| Line Rated Current | 9A |
| Main Power Pole Contact Form | 3NO |
| Maximum Voltage Rating | 600V AC |
| Nema Degree Of Protection | Not Rated (Open Device) |
| Nema Enclosure Material | Not Applicable |
| Nema Size | 0 |
| Nominal Coil Voltage @ 60hz | 120V AC |
| Number Of Auxillary Contacts | 2 |
| Number Of Poles | 3 |
| Overall Depth | 3.62" |
| Overall Height | 3.71" |
| Overall Width | 3.53" |
| Phase | Three |
| Product Or Component Type | Contactor |
| Reversible | Yes |
| Reversing Capability | Reversing |
| Series | TESYS N Series |
| Standards | Csa, Ul Listed |
| Terminal Connection Type | Screw Clamp Terminals |
| Width | 3.54" |
| Wire Termination Type | Screw Clamp |
| Height (cm) | 9.42 |
|---|---|
| Length (cm) | 9.19 |
| Width (cm) | 8.97 |
| HS Code | 8536490065 |
|---|---|
| Country Of Origin | FR |
| Weight (kg) | 0.945 |
| Style | Model | Nema Size | Full Load Amps | Hz | Hp @ 3 Phase - 575v | Action Type | Inductive Full Load Amps | Coil Voltage | Hp @ 3 Phase - 240v | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | T02AN23T7 | - | 9A | - | 2 hp | Reversing | 9 | 480V AC | 1.5 hp | $1,341.32 | |
| A | T02BN23G7 | - | 18A | 50/60 Hz | 5 hp | Reversing | 18A | 120V AC | 3 hp | $1,421.09 | |
| A | T02CN23G7 | 1 | 27A | 50/60 Hz | 10 hp | Reversing | 27A | 120V AC | 7 1/2 hp | $1,307.15 | |
| B | T02DN23G7 | 2 | 45A | 50/60 Hz | 25 hp | Reversing | 45A | 120V AC | 15 hp | $2,808.05 | |
| C | T02GN23G7 | 5 | 270A | - | 200 hp | Reversing | 270 | 120V AC | 100 hp | $29,506.62 | |
| D | T02HN13F7 | 6 | 540A | 40/400 Hz | 400 hp | Non Reversing | 540A | 120V AC | 200 hp | $23,076.25 | |
| C | T02HN23F7 | 6 | 540A | - | 400 hp | Reversing | 540 | 120V AC | 200 hp | $47,920.61 |
