| Item | Motion Control Coupling |
|---|---|
| Bore Dia. | 14 x 10 mm |
| Clearance Dia. | 41.30mm |
| Disc Type | Stainless Steel |
| Finish | Anodized Aluminum |
| Hub Dia. | 41.30mm |
| Length Through Bore | 27.5mm |
| Material | Aluminum |
| Max. Angular Misalignment | 2 Degrees |
| Max. Axial Misalignment (in.) | +/-.020 |
| Max. Parallel Misalignment (in.) | 0.010 |
|---|---|
| Max. Rpm | 10,000 |
| Max. Temp. Range (f) | 200 |
| Outside Dia. | 41.30mm |
| Overall Length | 55mm |
| Screw Size | M4 mm |
| Screw Type | Cap Screw |
| Style | Double Disc Clamp |
| Torque | 180 In.Lbs. |
| Torsional Stiffness (deg./in.-lbs.) | 0.002 |
| Height (cm) | 5.08 |
|---|---|
| Length (cm) | 15.24 |
| Width (cm) | 5.08 |
| HS Code | 8483608000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.1665 |
