| Item | Agricultural Disc Bearing |
|---|---|
| Abec Rating | 1 |
| Abec Tolerance | 1 |
| Application | Disc Harrows, Disc Tillers, Trenching Machinery |
| Ball Material | Steel |
| Bearing Industry Number | DS208TTR8 |
| Bearing Material | Steel |
| Bearing Type | Spherical Outer Ring, Square Bore |
| Bore Dia. | 1 1/8" |
| Bore Shape | Square |
| Bore Size | 1.18" |
| Bore Size Tolerance | -0.0004" to +0.0004" |
| Cage Material | Steel |
| Cage Type | Pressed |
| Closure | Double Sealed |
| Dynamic Load Capacity | 6550 lbs. |
| Dynamic Radial Load Capacity | 6542 lbf. |
| Flange Size | Not Applicable |
| Flange Type | Non Flanged |
| For Shaft Size | 1 1/8" |
|---|---|
| Housing Material | Alloy Steel |
| Iso Rating | Class 0 |
| Lubrication | Shell Alvania #3 |
| Max. Speed | 560 RPM |
| Maximum Temperature | 250°F |
| Minimum Temperature | -40°F |
| Number Of Rows | 1 |
| Outer Ring Type | Spherical |
| Outside Dia. | 3.149" |
| Overall Width | 1.437" |
| Ring Material | Alloy Steel |
| Ring Material Grade | Grade 52135 |
| Seal Material | Nitrile Rubber |
| Seal Type | Contact |
| Static Load Capacity | 4000 lbs. |
| Static Radial Load Capacity | 4002 lbf. |
| System Of Measurement | Inch |
| Width | 1.437" |
| Height (cm) | 8 |
|---|---|
| Length (cm) | 8 |
| Width (cm) | 3.65 |
| HS Code | 8482105052 |
|---|---|
| Country Of Origin | JP |
| Weight (kg) | 0.711 |
| Style | Model | Cage Material | Closure | Ball Material | Bore Dia. | Outside Dia. | Outer Ring Width | Max. Speed | Dynamic Load Capacity | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | CDS209TTR6P | Nylon | Double Sealed | Steel | 1.53" | 5" | - | 520 RPM | 7350 lbs. | $361.16 | |
| A | CDS211TTR23 | Nylon | Double Sealed | Steel | 1.78" | 4.438" | - | 450 RPM | 9750 lbs. | $477.51 | |
| B | DC208TT | Steel | Double Sealed | Steel | 1 1/8" | 3.149" | - | 560 RPM | 6550 lbs. | $277.34 | |
| C | DC208TT10 | Steel | Double Sealed | Steel | 1 1/2" | 3.149" | - | 560 RPM | 6550 lbs. | $196.80 | |
| B | DC208TT5 | Steel | Double Sealed | Steel | 1 1/8" | 3.149" | - | 560 RPM | 6550 lbs. | $153.16 | |
| B | DC208TT6 | Steel | Double Sealed | Steel | - | 3.149" | - | 560 RPM | 6550 lbs. | $220.59 | |
| B | DC208TT8 | Steel | Double Sealed | Steel | 1 1/8" | 3.149" | - | 560 RPM | 6550 lbs. | $182.50 |
