| Item | Ball Screw Support Bearing |
|---|---|
| Abec Rating | 7 |
| Ball Material | Alloy Steel |
| Bearing Industry Number | 45X75 |
| Bearing Type | Single Bearing |
| Bore Dia. | 45 mm |
| Cage Material | Nylon |
| Closure | Open |
| Contact Angle | 60° |
| Dynamic Load Capacity | 32000 lbs. |
| Dynamic Radial Load Capacity | 32000N |
| Finish | Chrome Plated |
| Housing Fillet Radius | 0.6 mm |
| Iso Rating | Class 4 |
| Load Direction | Thrust |
| Lubricant Material | Oil |
|---|---|
| Lubrication | Oil |
| Matched Bearing Type | Not Matched/Single Bearing |
| Maximum Temperature | 120°C |
| Minimum Temperature | -40°C |
| Number Of Rows | 1 |
| Outside Dia. | 75 mm |
| Overall Width | 15 mm |
| Ring Material | Alloy Steel |
| Ring Material Grade | AISI 52100 |
| Shaft Fillet Radius | 1 mm |
| Standards | Iso Certified |
| Static Load Capacity | 77500 lbs. |
| Static Radial Load Capacity | 77400N |
| Temp. Range | -22°F to +248°F |
| Height (cm) | 7.5 |
|---|---|
| Length (cm) | 7.5 |
| Width (cm) | 1.5 |
| HS Code | 8482105052 |
|---|---|
| Country Of Origin | JP |
| Weight (kg) | 0.2655 |
| Style | Model | Bore Dia. | Cage Material | Dynamic Load Capacity | Outside Dia. | Static Load Capacity | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|
| A | BST20X47-1BP4 | 20 mm | Phenolic | 24300 lbs. | 47 mm | 37500 lbs. | $596.23 | |
| A | BST25X62-1BP4 | 25 mm | Nylon | 29200 lbs. | 62 mm | 59000 lbs. | $706.03 | |
| A | BST30X62-1BP4 | 30 mm | Nylon | 29200 lbs. | 62 mm | 59000 lbs. | $705.00 | |
| A | BST35X72-1BP4 | 35 mm | Nylon | 31000 lbs. | 72 mm | 70000 lbs. | $747.24 | |
| A | BST40X72-1BP4 | 40 mm | Nylon | 31000 lbs. | 72 mm | 70000 lbs. | $846.89 | |
| A | BST40X90-1BP4 | 40 mm | Nylon | 56500 lbs. | 90 mm | 130000 lbs. | $1,008.87 |
