Ships within 2 days via
We deliver to your doorstep under DAP terms. Customs clearance is for your account
Business customers can apply for Net 30
No fees, No interest, Fast approval.
Payment
| Item | Swing Check Valve |
|---|---|
| 3-a Compliance | Not Rated |
| Application - Valves | General Purpose |
| Body Material | Brass |
| Cap To Inlet Center | 1.531" |
| Check Mechanism | Swing |
| Connection Gender - Side 1 | Female |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 1/2" |
| Connection Size - Side 2 | 1/2" |
| Connection Type | FNPT x FNPT |
| Connection Type - Side 1 | NPT |
| Connection Type - Side 2 | NPT |
| Cracking Pressure | 0.5 psi |
| Disc Material | Brass |
| Flow Coefficient (cv) | 10 |
| Flow Design | Single |
| Flow Rate | 10 GPM |
| For Media | Gas, Oil, Water |
| Full Flow - Valves | Yes |
| Height - Cap To Inlet Center | 1 3/8" |
| Includes Counterweight | No Counterweight |
| Length | 2 1/8" |
| Material | Low Lead Brass |
| Max. Pressure (cwp) | 200 psi |
| Max. Pressure (steam) | Not Rated |
|---|---|
| Max. Steam Pressure - Valves | Not Rated |
| Max. Temp. | 150°F |
| Media Temp. Range | -20°F to +150°F |
| Media Temperature Range | -20°F to +150°F |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Orientation - Check Valves | Horizontal, Vertical |
| Mounting Position | Multi Position |
| Nsf Certifications For Food And Drinking Water | NSF 61 |
| Operating Temperature - Maximum | 150°F |
| Operating Temperature - Minimum | -20°F |
| Overall Height | 2.094" |
| Overall Length | 1.86" |
| Pipe Size | 1/2" |
| Seal Material | Brass |
| Seal Material - Check Valves | Brass |
| Seat Material | Brass |
| Seat Material - Check Valves | Metal |
| Silent Check | Standard |
| Standards | Nsf/Ansi 372 |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Inline |
| Valve Series | UP967 Series |
| Width | 1" |
| Height (cm) | 3.81 |
|---|---|
| Length (cm) | 5.08 |
| Width (cm) | 5.08 |
| HS Code | 8481301090 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 0.18 |
| Style | Model | Connection Type | Pipe Size | Max. Temp. | Cracking Pressure | Cap To Inlet Center | Flow Rate | Overall Height | Body Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | UP0967000034 | FNPT x FNPT | - | 151°F | 0.5 psi | 1 5/8" | 18 GPM | 2.297" | Brass | $134.57 | |
| A | UP0967000100 | FNPT x FNPT | - | 152°F | 0.5 psi | 1.781" | 31 GPM | - | Brass | $181.44 | |
| A | UP0967000114 | FNPT x FNPT | 1 1/4" | 153°F | 0.5 psi | 2" | 54 GPM | 2.906" | Brass | $296.09 | |
| A | UP0967000112 | FNPT x FNPT | 1 1/2" | 154°F | 0.5 psi | 2 1/4" | 76 GPM | 3.297" | Brass | $337.06 | |
| A | UP0967000200 | FNPT x FNPT | - | 155°F | 0.1 psi | 2.688" | 131 GPM | 3.844" | Brass | $521.01 | |
| B | UP0968000012 | Sweat x Sweat | - | 156°F | 0.1 psi | 1.531" | 10 GPM | 2.094" | Brass | $118.13 | |
| B | UP0968000034 | Sweat x Sweat | - | 157°F | 0.1 psi | 1 5/8" | 18 GPM | 2.297" | Brass | $140.57 |
